Yamaha R15 Key Cutting by Xhorse Dolphin XP005 Machine

This instruction show you guide on how to use Xhorse Dolphin XP005 and VVDI Key Tool Max to cutting key for Yamaha R15.

Note:Here VVDI Key Tool only for cutting operations.

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-1



Procedures:
Before operation,please pairing your Xhorse Dolphin XP005 to VVDI Key Tool Max

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-2

Select “YAMAHA-R15”

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-3

Install Clamp M2 and put working key on,then align it to position

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-4 Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-5



Decode key

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-6 Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-7



If it is all key lost situation,you can use Lishi tool to do decode

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-8

After decoding completly,put R15 blank key on M2 clamp,then press “Cutting Key”

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-9

Set low speed and 3 cutting times…

And recommend to use 1.5mm

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-10 Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-11



One side cutting successfuly,now change key to another side for cutting

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-12 Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-13

Test new key

Yamaha-R15-Key-Cutting-by-Xhorse-Dolphin-XP005-Machine-14



Xhorse Dolphin Decode HU92 Laser Key by Photo Scan Function

In this instruction,keycuttingmachine blog will show you guide on how to use Xhorse Dolphin Machine photo scan function to decode HU92 laserkey.



Run Xhorse app on your mobile phone

Enter “Vehicle Database” or “Cut by Bitting” option

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-1

Select proper model and key blank

BMW–>330

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-2 Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-3



Press “OK” to cotinue

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-4

Click on “Decode key”

Select “Learn key via photo” to continue

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-5

Take a photo of the original key or use photos from album

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-6

Please move key blade align the picture

Rotate and zoom in the photo,adjust photo the align line.

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-7

Top align keys,top position align at green line

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-8

Move the white point to the current bitting overlap with green line position

Adjust each bitting position one by one

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-9

After the,click “Next” to decode key,it will show the key code on Xhorse app and ready for cutting.

Dolphin-Decode-HU92-Laser-Key-by-Photo-Scan-Function-10

http://www.uobdii.com/wholesale/xhorse-condor-dolphin-key-cutting-machine.html

Xhorse Dolphin XP005 and XP007 – What’s the different?

Here, we’ll talk about the difference between XP-005 and XP-007 Xhorse dolphin key cutting machines.

Xp005 is automatic machine working with phone app. it’s good machine ,fast n easy on the job.

xp007 is manual and has limitations. relies on your skill of locksmithing or requires keymoulds for all key lost situation.but it’s also good for cloning keys.

Xhorse Dolphin XP005 vs. XP007 Key Cutting Machine

Overally, xp005 and xp 007 are both good tools that a locksmith should have. if you are a learning locksmith start with xp005 its good for learning

Attachment: Specification Dolphin XP005 and XP007

Key cutting machine Dolphin XP-007 Dolphin XP-005
Working temperature: 0~50℃ 0~50℃
Working Humidity: 10%~90% 10%~90%
Battery capacity: 64.75 w.h 64.75 w.h
Motor Rotation Speed: Highest: 13000 RPM;

switch 1: 7000 RPM;

switch 2: 10000 RPM

10000-13000RPM



Machine Dimension: 282×246.5x355mm 315x218x270mm
Package Dimension: 365x325x350mm 510x315x345mm
Travel of spindle 25mm  –
Table travel transverse: 36m
portrait: 48mm
 –
Net Weight: 11.55KG 15kg
Gross Weight: 14KG 18kg



How to Use Xhorse XC-Mini Cut Key for GMC B102 Key

Here keycuttingmachine.org will show the procedures on how to use Xhorse XC-Mini to cut GMC B102 key.Now this key cutting machine is stop production,the replacement is Xhorse Condor XC-MINI Plus



Steps:

Select Car Maker “GMC”,then click Confirm

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (1)

Input key code:S591B

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (2)

S000A-S999K

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (3)

Use Clamp M1

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (4)

Put the blank key on the clamp M1

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (5)

proceed cutting work

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (6) How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (7) How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (8) How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (9)



it will start next side cutting working

How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (11) How to Use Xhorse XC-Mini Cut Key for GMC B102 Key (12)



Cutting done!

Automobile Key Cutting Machine Reviews from Forum

Here, have collected answers under a post about ” What kinds of key cutting machine do you use?”



James Kennedy Triton



Fórizs Józsi Xhorse condor Mini , silca 2000 and some cheap chinese cutters



Óðinn Sigurðsson Silca Unocode 299 and 399, Silca Triax, Silca Idea, Miracle 9 and then a few copiers


Robert N. Simmons Jr. Rytan 256, Framon 2, XHorse Mini Condor Plus, Scotsman in the truck.


Jorge Aguilar XHorse Dolphin


Марин Узунов Miracle A9


Heriberto Padilla Xhorse dolphin



Aylin Cherkez Xhorse dolphin



Joe Taylor Maurice plus mini and sec 9



Jeremy Causey Xhorse condor xc-009, dolphin xp-007 and dolphin xp-005 all cordless great for mobile service no need for a heavy duty power inverter if you have a van

its portable no need to plug it in that’s the main difference other than the touchscreen other then that they do everything else the same



Ignat Ignatov Gymkhana 994



Dan Florko 2- itl959c ‘s
Matrix retro
KD50
Rytan
Silca
Delta fo (tibbe)
Scotsman
And more to come soon





Conclusion:

The most popular is Xhorse key cutting machine

Top 1 xhorse key machine is the Dolphin

xhorse_dolphin_key_cutting_machine

source: http://www.uobdii.com/wholesale/xhorse-condor-dolphin-key-cutting-machine.html

DOLPHIN is the latest portable automatic key cutting machine with a built-in battery inside.

It has all the capabilities of Condor XC Mini.

Dolphin works on mobile phone application via bluetooth connection. There is no touchscreen, instead you interface with the machine via the mobile phone or tablet.

M1/M2 Jaws included.

M3 Jaw – optional purchase.



Specifications:

Working temperature: -10~50℃

Working Humidity: 10%~90%

Battery capacity: 64.75w.h

Standby power: 15W

Motor Rotation Speed: 10000-13000 RPM

USB Port: USB2.0

Machine Dimension: 315x218x270mm

Net Weight: 15KG

Gross Weight: 18KG

POWER: 100W



POWER PARAMETER: 12-24V

MOTOR TORQUE: 0.15Nm

Features:

Precision Production: All aluminum body structure, Manufactured by Germany-made DMG CNC machine

Data Richness: Provide rich vehicle data, blank key data, the best tool of all key lost.

Built-in Lithium Battery: Optimized lithium battery of well-known brand, stable and reliable, support cutting under no power conditions.

Clamps: Standard equipped two clamps M1 and M2, supports Sided, Track, Dimple and Tibbe keys. Optional M3 clamp and M4 clamp are available, M3 clamp is applicable to Ford FO21 & Citroen SX9 keys, M4 clamp is applicable to single-sided house-keys (duplication only).

One year warranty

Intelligent Control: Provide powerful free App, support multi-language, support mobile phone, tablet computer and other intelligent terminal control, easy for operations.

High Efficiency Cutting: Use American famous brushless motor and screw rod, high efficiency and stability, create high precision cutting quality.

Online Update: Provide free software upgrade service, software function and database.





Accessories:

M1 Clamp – included

M2 Clamp – included

M3 Clamp (optional)

Xhorse Doliphin Duplicate Honda Key in 5 Minutes

This is a feedback by a real Xhorse Dolphin XP005 machine user on Honda key cutting.

Build connection between mobile phone and Dolphin XP005,then select “Honda” and duplication function.Put the original key on the clamp to get the key code number

Xhorse Doliphin Duplicate Honda Key in 5 Minutes (1) Xhorse Doliphin Duplicate Honda Key in 5 Minutes (2) Xhorse Doliphin Duplicate Honda Key in 5 Minutes (3)

When decoding completing,remove the original key from Dolphin xp005 and put new key on the clamp

Xhorse Doliphin Duplicate Honda Key in 5 Minutes (4)

The press “Cut” button to start cutting work

Xhorse Doliphin Duplicate Honda Key in 5 Minutes (5) Xhorse Doliphin Duplicate Honda Key in 5 Minutes (6) Xhorse Doliphin Duplicate Honda Key in 5 Minutes (7)



After first side cutting work complete,just put it on the other side to cut

Xhorse Doliphin Duplicate Honda Key in 5 Minutes (8)

After then test it on the door lock

Xhorse Doliphin Duplicate Honda Key in 5 Minutes (9) Xhorse Doliphin Duplicate Honda Key in 5 Minutes (10)



Done!

http://www.uobdii.com/wholesale/xhorse-condor-dolphin-key-cutting-machine.html

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster

This instruction show you guide on how to use Xhorse Condor Mini Plus machine to cut new key for Renault Duster by key code.



Procedures:

Enter menu to select “Renault”

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (1)

Input the key code “264”,then press “Confirm”

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (2)

Series:0001-4092

Cuts:6

Compatible Key:Silca

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (3)

Now press “Cut” button to start cutting work

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (4)

Cutting work process…

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (5) Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (6) Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (7) Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (8) Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (9)



Remove the key from clamp,and test on the lock.

Xhorse Codnor Mini Plus Cut New Key for Renualt Duster (10)

Source: http://www.uobdii.com/wholesale/xhorse-condor-mini-plus.html

How to Use Condor XC-Mini Plus Key Cutting Machine

This instruction show you guide on how to use Xhorse Condor XC-Mini plus machine,include cutter installation & uninstallation,clamp installation,clamp instruction..ect.



Installation Instruction:

Cluster installation

Installation steps:

1 Put the cutter into the mounting hole and make sure the cutter goes to the limit of top.

2 Use the cutter tightening wrench to clockwise fix the cutter.

How to Use Condor XC-Mini Plus Key Cutting Machine-1

Cutter Uninstallation:

Uninstallation steps:

1) Counter-clockwise unscrew the cutter manually.

2) Take the cutter off when it is loose

How to Use Condor XC-Mini Plus Key Cutting Machine-2



Clamp Installation

Installation Step2:

1) Loosening the clamp tightening wrench by turning it counter-clockwise to the left.

2) Select the correct clamp and slide in the clamp to the clamp holder and push it to the limit of left.

3) After the clamp is put in the clamp platform,turn the clamp tightening wrench clockwise for fix it.

How to Use Condor XC-Mini Plus Key Cutting Machine-3



Clamps Instruction:

How to Use Condor XC-Mini Plus Key Cutting Machine-4 How to Use Condor XC-Mini Plus Key Cutting Machine-5





Clamp M2 Sides Selection

How to Use Condor XC-Mini Plus Key Cutting Machine-6



6 Clamp M4 Instruction

Clamp M4 for household keys, mainly support standard single and double sided keys,also for

crucifix keys,example as follows:

How to Use Condor XC-Mini Plus Key Cutting Machine-7 How to Use Condor XC-Mini Plus Key Cutting Machine-8

http://www.uobdii.com/wholesale/xhorse-condor-mini-plus.html

How to Update Condor Mini PLUS Firmware ?

Tips and guides for those with Condor xc-mini plus key machines:

Upgrade kit download:



The are 3 ways to get ‘Upgrade kit’ file for firmware update



  1. Contact your distributor ask for the software.
  2. Contact Xhorse technical support skype: Live: condor_keymachine@hotmail.com
  3. Scan the QR code to download and install Xhorse APP.



condor-mini-plus-online-update-user-guide-1

update tool.rar

condor-mini-plus-online-update-user-guide-2

Scan QR Code to download Xhorse APP



Steps to update Condor mini plus firmware:



Step 1:

Unzip the Upgrade kit file after the file has been downloaded .

condor-mini-plus-online-update-user-guide-3

Step 2:

Run ‘Upgrade Kit.exe’ and connect the machine with the pc

Do not turn off the machine during update process

and also the upgrade kit software will be updated automatically

condor-mini-plus-online-update-user-guide-4

Step 3:

Open the file of ‘Driver’ from those decompressed files

and choose a relatively new driver to install

If the computer still can not recognize the machine after the installation of the driver, it is advisable to change to another driver.

If all the drivers fail, please contact your distributor or technical support from the manufacturer.

condor-mini-plus-online-update-user-guide-5

Step 4:

After the machine is successfully communicated with the computer, read the serial number, then select the XC-MINI PLUS and click to update.

Note: Please keep the machine connected to the computer by USB during the update.

condor-mini-plus-online-update-user-guide-6

Attachment: Condor mini plus user manual.pdf
