How to Use OBDSTAR X300 DP Plus Do Ford Escort 2018 All Key Lost Programming

This article show a guide on how to use OBDSTAR Key Master DP Plus to program new keys for Ford Escort 2018 all keys lost.

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (1)





Here is OBDSTAR Key Master DP Plus Do 2018 Ford Escort All Keys Lost Video Guide:





Procedure With Pictures and Texts:

Connect OBDSTAR X300 DP Plus to Ford Escort by OBD port

Enter main menu–>Diag Program–>Immobiliser–>Ford Lincoln

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (2)

Select “FORD/LINCOLN V32.23” then click “Enter” to continue

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (3)

Select “FORD”

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (4)

Select “Immobiliser”

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (5)

ESCORT

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (6)

Select year after 2017 “2017-”

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (7)

Select “Erase Keys”

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (8)

Instruction:

All keys will be erased

Min keys are required:2

Press Enter to continue

Turn the ignition to ON position,then click “Enter” to continue

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (9)

You need to wait a minute for system reading data…

When the system configuration completing,it will prompt to follow below operations:

1.Switch ignition off

2.Switch ignition on with key 1 for 3 seconds,then switch off and remove the key

3.Swtich ignition on with key 2 for 3 seconds,then switch off and remove the key

4.If you want to add more keys,please repeat procedure 3,complete

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (10)

Press “Enter” to continue

Test programmed keys on the vehicle

Ford Escort 2018 All Key Lost Programming by OBDSTAR X300 DP Plus (11)

Done!

How to Use OBDSTAR X300 DP Plus Read Fiat Delphi 93c66 PIN Code

This article show a OBDSTAR X300 DP Plus test case on Fiat Delphi 93C66 PIN code reading.If you want to get more test case,check here:OBDSTAR X300 DP Plus test cases.

This article show a OBDSTAR X300 DP Plus test case on Fiat Delphi 93C66 PIN code reading.If you want to get more test case,check here:OBDSTAR X300 DP Plus test cases.



Procedures:

Connect OBDSTAR X300 DP Plus to Fiat,then enter the menu to select “FIAT V32.00”

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (1)

After waiting a moment for system build connection and configuration

Tap “Pre-Coding”

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (2)

Select “DELPHI 93C66(B)(ID48)”

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (3)

Vehicle equipped with this unit:

Albea,Doblo(2000-2010),Punto,Palio,Strada

Tap “Yes” to continue

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (4)

OBDSTAR X300 PAD2 will give the massage:

This function is available by connecting the server,please ensure the internet connection is normal

Tap “Enter” to continue

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (5)

After then you need to select “Read EEPROM(93C66)”,the tap “Enter” to continue

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (6)

Follow the screen prompt to switch ignition on

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (7)

Switch ignition off

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (8)

Then switch the ignition on again

Logging,please wait about 5 minutes…

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (9)

Please enter a filename to save

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (10) OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (11)



Now you can get the PIN code

OBDSTAR X300 DP Plus Read PIN Code for Fiat Delphi 93c66 (12)

Done!



How to Use OBDSTAR X300 DP Plus Read Fiat Delphi 93C66 PIN Code

Obdstar X300 DP Plus Configuration A vs Configuration B vs Configuration C

What is Obdstar X300 DP Plus Configuration A, B, C?

OBDSTAR-x300-dp-plus-for-sale

It’s a new OBDSTAR tool built with Android-based, used for vehicle diagnosis, coding, programming (key programming and ecu programming) and special functions (incl. odometer correction). It inherits from OBDSTAR advanced diagnosing technology and it is characterized by covering wide range of vehicles, featuring powerful function, and providing precise result. Through vehicle diagnostic OBD connector and variant mobile intelligent terminals, it achieves vehicle trouble diagnosis for full car model and full system vehicle.

There are three versions of Obdstar X300 DP Plus:

Configuration A, B and C coming with different features/function.

Look at the chart below in detail…

Obdstar X300 DP Plus Configuration A vs Configuration B vs Configuration C



Obdstar X300 DP Plus A Configuration

(Basic version)

B Configuration C Configuration

(Full version)

Image  obdstar-x300-dp-plus-a-package  obdstar-x300-dp-plus-b-package

obdstar-x300-dp-plus-c-package

Price 1699 usd 1849 usd 1999 usd
Diagnosis No No Yes

(full-system diagnosis)

Immobilizer Yes Yes Yes
Odometer correction No Yes Yes
OBDII No No Yes
EEPROM Yes Yes Yes
Key Renewing Yes Yes Yes
Oil reset No No Yes
ABS No No Yes
Battery matching No No Yes
ECU programming No No Yes
EPB No No Yes
Throttle programming No No Yes
Airbag reset No No Yes
TPMS No No Yes
Steering angle reset No No Yes
DPF No No Yes
Injector coding No No Yes
Suspension matching No No Yes
Gear learning No No Yes
CVT learning No No Yes
ECU cloning No No Yes
P001 programmer Yes Yes Yes
C001 circuit board Yes Yes Yes
C002 circuit board Yes Yes Yes
W001 data cable Yes Yes Yes
W002 data cable Yes Yes Yes
W003 data cable Yes Yes Yes
Toyota smart key Emulator Yes Yes Yes
Ignition coil Yes Yes Yes
Remote tester Yes Yes Yes



X300 DP Plus A Package – used as a universal key programmer for locksmiths

Immobilizer+Special function(EEPROM+Key Renewing)Adapter(P001 programmer+C001circuit board+C002 circuit board+W001 cable+W002 data cable+W003 data cable+Toyota smart key Emulator)+others(Ignition coil+Remote tester)



X300 PAD2 B Package – works as an auto key programmer and a odometer correction tool

Immobilizer+Special function(EEPROM+Key Renewing)+Mileage correction+Adapter(P001 programmer+C001 circuit board+C002  circuit board+W001 data cable+W002 data cable+W003 data cable+Toyota smart key Emulator)+others(Ignition coil+Remote tester)



X300 DP Plus C Package – is a 3-in-1 tool for auto repair shops (auto diagnostic tool + car key programmer + programming tool for special functions)

Immobilizer+Mileage correction+Diagnosis+Special function (Oil reset +ABS+Battery matching+ECU programming+EPB+Throttle programming+Airbag rest+TPMS+Steering angle reset+OBDII+DPF+Injector code+Suspension matching+Gear learning+CVT learning+EEPROM+Key renewing+ECU cloning)Adapter(P001 programmer+C001 circuit board+C002 circuit board+W001 data cable+W002 data cable+W003 data cable+Toyota smart key Emulator)+others(Ignition coil+Remote tester)



IMPORTANT: OBDSTAR X300 DP Plus Immobilizer Car List



European cars:



VW/Audi/Skoda/Seat: Configuration C is able to program new keys to NEC 24C64 2014- (Configuration A is NOT able to…)

BMW: Configuration C is able to program FEM/BDC keys and read ISN codes (Configuration A is NOT able to…)

VOLVO: All X300 DP Plus versions CAN program/add new keys to Volvo

Also, X300 DP Plus A, B, C versions supports other cars made in Europe but not mention here…

Asian cars:

Hyundai/Kia: Configuration C is able to read pin codes of 47/8A/46 smart keys (Configuration A is NOT able to…)

Toyota/Lexus: The middle western version is able to program a new key with a H chip when all keys are lost (with the immo box reset)

Also, X300 DP Plus A, B, C versions supports other cars made in Asia but not mention here…

American cars:

Ford: Configuration C is able to program new keys to post-2015 Ford such as Mondeo, Edge, Taurus, ESCORT, Everest, Explorer, Raptor F-150, Raptor F-250, Mustang, Lincoln MKZ, MKC, Continental 2015 – etc. (Configuration A is NOT able to…)

GM: Configuration C is able to read BCM password of Buick LaCrosse (pre-2017), Envision, Trax, GL8, Malibu, Chevrolet Aveo, Excelle (pre-2015), Cruze, etc.  (Configuration A is NOT able to…)

Also, X300 DP Plus A, B, C versions supports other cars made in America but not mention here…

YOU HAVE TO KNOW: Why you should have a new Obdstar X300DP Plus instead of the old X300 DP and Lonsdor K518ISE?

Obdstar X300DP Plus vs Obdstar X300 DP:

X300 DP Plus has been improved a lot in hardware and supports more functions especially Toyota smart key card program and 8-pin chip data read.

In detail..

Obdstar X300DP Plus vs Lonsdor K518ISE:

Lonsdor k518ise is a tool for key programming only! It’s for locksmiths.

Obdstar x300 dp plus is a tool with diagnosis, immo and special functions 3 in 1. it’s a good helper to auto repair shops.

In detail…

Volvo Key Programmer,Which is Highly Recommend?

There are top 3 Volvo key programmers which covers all Volvos that Tango & tmpro2 don’t cover, they are: OBDSTAR X300 DP, OBDSTAR X300 Pro3 and Lonsdor K518ISE etc.

There are top 3 Volvo key programmers which covers all Volvos that Tango & tmpro2 don’t cover, they are: OBDSTAR X300 DP, OBDSTAR X300 Pro3 and Lonsdor K518ISE etc.



OBDSTAR X300 DP & OBDSTAR X300 Pro3 on Volvo IMMO

OBDSTAR X300 DP or X300 Pro3 support Volvo Semi smart key programming all keys lost and add keys, and no need to disassemble CEM / KVM.

OBDSTAR Volvo IMMO list:

S60 (2011 – 2017)

S80 (2009 -2016)

V40 (2012 – 2017)

V60 (2011 -2016)

V70 (2009 -2016)

X C60 (2009-2017)

XC70(2007-2016)

Keep updating……

obdstar volvo immo update



Reliable source of OBDSTAR X300 DP / X300 Pro3 with Volvo IMMO functions:

OBDSTAR X300 DP full package: free to upgrade Volvo IMMO function

OBDSTAR X300 DP standard package: pay 60USD to upgrade Volvo IMMO function

OBDSTA X300 Pro3 full package: pay 60USD to upgrade Volvo IMMO function

OBDSTA X300 Pro3 standard package: pay 60USD to upgrade Volvo IMMO function



OBDSTAR X300 DP IMMO & remote vehicle coverage & OBDSTAR X300 PRO3 IMMO & remote vehicle coverage:

visit http://en.obdstar.com/ then “Carlist” -> “Function List”-> “Immobilizer”, then click the specific car model to have details.



Lonsdor K518ISE Programmer

Volvo (S40, S60, S80, XC60, XC90, C30, C70, V40, V60, V70) key programming best choice is Lonsdor K518ISE.

 lonsdor-k518ise



Lonsdor K518ISE Volvo Coverage:

Series     Origin     Year     Fuel Type     Function

S60        Other      Other    Other         Proximity Key[insert key to start]

S60        Other      Other    Other         Smart Key[one-button start]

S80        Other      09-      Other         Smart Key[one-button start]

XC60       Other      09-      Other         Smart Key[one-button start]

S80        Other      09-      Other         Proximity Key[insert key to start]

XC60       Other      09-      Other         Proximity Key[insert key to start]

S40        Other      Other    Other         Smart Key

S40        Other      Other    Other         Key Programming

S80        Other      -09      Other         Proximity Key[insert key to start]

V40        Other      Other    Other         Proximity Key[insert key to start]

C30        Other      Other    Other         Key Programming

C30        Other      Other    Other         Smart Key

V40        Other      Other    Other         Smart Key[one-button start]

S80        Other      -09      Other         Smart Key[one-button start]

V60        Other      Other    Other         Proximity Key[insert key to start]

V60        Other      Other    Other         Smart Key[one-button start]

XC60       Other      -09      Other         Proximity Key[insert key to start]

XC60       Other      -09      Other         Smart Key[one-button start]

XC90       Other      Other    Other         Flip Key

C70        Other      Other    Other         Key Programming

C70        Other      Other    Other         Smart Key

V70        Other      09-      Other         Proximity Key[insert key to start]

V70        Other      09-      Other         Smart Key[one-button start]



Lonsdor K518ISE real test results:

Lonsdor K518ISE-Volvo S60 Smart Key-half-keyless

Lonsdor K518ISE program Volvo XC60 smart key via OBD

Lonsdor K518ISE program Volvo S40 key and remote key



Lonsdor K518ISE key programmer car list

Lonsdor K518ISE mileage correction car list

For newest car list, better visit the official site: http://en.lonsdor.com/



Update:

Update firmware & software on official site: http://en.lonsdor.com/.



To sum up:

Both Lonsdor K518ISE and OBDSTAR can work on Volvo IMMO & remote.

Lonsdor K518ISE work out Volvo key programming for half an year, and OBDSTAR is newly updated.



Lonsdor K518ISE is more expensive than OBDSTAR, while they have a different vehicle coverage (see the car list details), for which one to go for, it depends on what more car brands you want to work with.

VW Amarok Odometer Correction 2711 check fail by OBDSTAR X300 DP

Several days ago,one of obdstar tool customers sent e-mail to ask how to correct odometer for VW Odometer.And he get into trouble of “2711 check fail!” when correcting odometer for VW Amarok by OBDSTAR X300 DP .

Customer:

I tried doing mileage adjustment on the VW Amarok, however it gives me the error as in the picture

Solution:VW Amarok Odometer Correction 2711 check fail

Here obdstartool engineers share the method to solve this problem.

Solution:

If you ever wonder, to adjust the VW Amarok Odo, you need to choose Golf, NEC+24C64, then VDO-12 and it will complete change.

OBDSTAR Tech Advice:

For VW mileage correction, engineer said it depends on cluster model more than the car model

More support,pls contact:

http://www.obdstartool.com

AutoProPad vs Obdstar X300 DP

Found an interesting discussion in a Facebook group. Copied here for all. Hope it helps.

Found an interesting discussion in a Facebook group. Copied here for all. Hope it helps.

OBDSTAR DP PAD

Bid thanks to Kin Lee and Andrew Cuillo



Topic: AutoProPad and Obdstar X300 DP key master, which one should you have?



Kin Lee: That AutoProPad’s the same platform as X-100 Pad 2 & double the cost, after 1st year will cost $900 a year where OBDSTAR’s only $170 a year for updates. Anytime a USA company takes over expect the price to pay much more with promises of good things to come, but will it come?



Andrew Cuillo: I have had autopropad and I haven’t had any problems they have tech support in us and team helping the us market add more cars nissan Smart keys are super quick



Kin Lee: Plus I seen AutoProPad do a 5 into 4 pin Nissan system & you need to read BCM write it down then enter it manually back into it then it’ll gave old & new pin where’s ODBSTAR does all this with 1 push



Andrew Cuillo: did u know the person who made ikey used to work for xtool



Andrew Cuillo: This is nissan



Kin Lee: ok used too so he no longer does



Kin Lee: what’s that pic of Toy or Nissan 20 pin?



Andrew Cuillo: Nissan Smart keys 4digit pin

Unlocks goes into programming just insert key and done



Kin Lee: every good Chinese tool does Nissan 20 pin Smart keys super fast & IKEY does it the fastest I ever used



Andrew Cuillo: And autopropad can do some bmws too



Kin Lee: http://obd2-diag.blogspot.com/2018/02/obdstar-x300-dp-bmw-fembdc-key.html

OBDSTAR X300 DP BMW FEM/BDC smart key…



Andrew Cuillo: here is our group for it

https://m.facebook.com/groups/110842182807563

AutoProPAD USA-(AutoProPad-LITE)



Kin Lee: what you doing after the 1st year? Paying $900?



Andrew Cuillo: $1000 a year



Kin Lee: http://www.lockpicks.com/…/autopropad-1-year-updates…/



AutoProPAD 1 Year Updates & Support Subscription -by XTool



Kin Lee: $1000



Kin Lee: I just read Ray-Ray said $900 in a group



Andrew Cuillo: yes they give u one year for free Carey at American Key is the master distributor



Kin Lee: I know the 1st year is free with every tool & I’m talking about after that!



Andrew Cuillo: $1000 a year

Amanda has one



Kin Lee: that’s my point!! $1k after the 1st year OBDSTAR’s only $170, it’s just like Launch charges $900 after the 1st year & MyTab’s only $150



Kin Lee: I think your missing my point here, AutoProPad cost $2700 to buy & $1k after the 1st year, X300 DP cost $800 to buy & cost $170 the next year, so tell me how much better does $2700 get you in 2 years?



Kin Lee: And in 2 years X300 DP is still have faster CPU, bigger RAM, long lasting battery and higher resolution.



Andrew Cuillo: Kin Lee I see what your saying I got mine in the beginning for $1800 when there is something wrong I have someone to call and get the software fixed if there is a problem



Kin Lee: on top of all that OBDSTAR’s leading the way on VAG’s right now, look at their OBDSTAR H110 I added a key to an 10 A6 in under 2 min as well as a 16 Jetta, can Autopropad do that too?



Andrew Cuillo: I know the other one is cheaper and faster I haven’t tried it yet maybe my next programmer will be x300 dp



Kin Lee: I’m looking for my next tablet to buy & all my research is pointing to OBDSTAR



Kin Lee: If I wanted a high dollar tablet that claims to be the best but running on a old platform I would have waiting a few more months & traded in my MVP for the Dumb Pro!



Kin Lee: The bottom line’s no 1 tool will ever do it all & I’m always looking for the best BANG for the $$, so I don’t mind having multi tools to get the jobs done without spending a lot & I’m pretty good @ that!!



Kin Lee: I just saved over $200 a years on auto insurance & got much more coverage from $25k/$50k to $100k/$300k & renters insurance for less $$ & I now pay $30 less a month with lots more coverage!! This is what I’m talking about paying more don’t always get you more in life!!

New! OBDSTAR H108 PSA Programmer for IMMO and dashboard

OBDSTAR H108 PSA immobilizer programming and dashboard reset can perform BSI model automatic identification and pin code reading when all keys lost, can read write EEPROM and FLASH etc. OBDSTAR H108 device adopts the upgraded main board which allows user to test more freely, operate more easily and offer better user experience. obdstar H108 is target to after-sale market, repair shops, car technicians and car owners.

obdstar-h108-psa-programmer



Features:

  1. Support BSI model automatic identification and manual selection
  2. Read Pin code when all keys lost
  3. Read write EEPROM, read FLASH.
  4. Competitive price comparing with the similar devices ie. PSA read PIN BSI(PTP2), PT0004 Read PIN in PSA by OBD.

Function list:

obdstar-h108-psa-programmer-02

Note: for the specific car model, please refer to the car list.



1.4 Functions Setting

Power on, and then press ENTER on the screen, then go to the function setting, setting information as shown below:

obdstar-h108-psa-programmer-03

1.4.1 Function Selection

Select different functions according to different requirements.

obdstar-h108-psa-programmer-04

Note: Software numbers and functions are different according to different product configuration. Further detailed information, please contact your distributor.

1.4.2 System Setting

Select System Setting, language and font can be adjusted, as shown below:

obdstar-h108-psa-programmer-05

1.4.2.1 Language Selection

This device supports English. In the language directory, select required language  and press ENTER to confirm it.

obdstar-h108-psa-programmer-06

1.4.2.2  Font setting

According to requirement, select different font

 obdstar-h108-psa-programmer-07

1.4.2.3 Metric/Inch

According to different requirements, select the Metric/Inch by the up and down keys, and press ENTER to confirm as show below,

obdstar-h108-psa-programmer-08



1.4.2.4 Data Logging

Any problems during testing, please use the Data Logging function to record the test process and send the data to us. Select ON by the up and down keys and press ENTER to confirm, shown as below,

obdstar-h108-psa-programmer-09

Note: Every time you need to select ON if you want to record the data before testing car.

1.4.3 System Information

System information includes product serial number, hardware version,software version, release date, register password, etc.

obdstar-h108-psa-programmer-10

1.4.4 Device Self-test

Device self-test includes screen display, keyboard testing. hardware self-testing, etc. If it cannot show enough pictures on the screen, keyboard not work, and hardware self-test not get through, pleasereturn this productto the manufacturer.

 obdstar-h108-psa-programmer-11

Chapter 2: How to update software for

2.1 Update tool software installation

Login our website:http://en.obdstar.com and click “One Key Upgrade”.

Download the update tool and diagnostic software, double click, then go to the next step:

Step 1:Click Next

obdstar-h108-psa-programmer-12

Step 2: Click Next

obdstar-h108-psa-programmer-13

Step 3: Wait for several minutes then the installation finished

Step 4: Click Finish

After Update Tool installation completed, click the Update Tool software icon        on desktop to start the update tools. The main interface is as shown below:





2.2Register

Click ”Sign up” to fill in user information, Username can be English characters or the combination of alphabet and numbers.

Serial number and register password can be referred to System information in the device.( Figure 1.4.3)

For distributor code, please refer to your distributor for more details.

2.3 Software updating

Operation steps as following:

Step 1: Remove the TF card from your device.

Insert your TF card into computer.

Step 2:Open update tool and login.

Step 3: Click the source menu, choose the software you want to update, click it and confirm.

Step 4: Click and select all the software then click “update”. (Note: It is better to click “Format memory car” during updating.)

Step 5: Wait for several minutes then the updating finished.



Note:For new update software and questions during updating, please contact your distributor.

OBDSTAR X300 DP PAD All Key Lost Programming for FORD Everset 2015

Guide on how to program FORD Everset 2015 all keys lost with OBDSTAR X300 DP PAD. It is very simple to operate.

Guide on how to program FORD Everset 2015 all keys lost with OBDSTAR X300 DP PAD. It is very simple to operate.



Tools to prepare:

2 orginal new keys

1 OBDSTAR X300 DP

Guide on how to program FORD Everset 2015 all keys lost with OBDSTAR X300 DP PAD. It is very simple to operate. Tools to prepare: 2 orginal new keys 1 OBDSTAR X300 DP 图1 Procedure: 1. Use the two keys to try to turn on the ignition, they are blank new one. 2. Open X300 DP PAD, go to option: Immobilizer Ford 图2 Immobilizer 图3 Select car model and year 图 5 6 7 2015- 图8 Type 1 图9 All keys lost 图10 Confugring the systerm, please wait... 图11 Switch ignition off 12 Press Emergency flasher switch 13 Open the driver door 14 Then close the driver door. Confugring the systerm, please wait... 15 You have to complete the following procedure, engine can be started: 1. Switch ignition off. 2. Switch ignition on with key 1 or 3 second and then switch off and remove the key. 3. Switch ignition on with key 2 or 3 second and then switch off and remove the key. 4. If you want to add more keys, please repeat procedure 3. complete. 16 FORD Everset 2015 all keys lost key programming done with BDSTAR X300 DP PAD. Tehch support by obdstar engineers. Have original obdstar X300 DP PAD on the authorized dealer www.uobdii.com. Tip: the following pictures are green Key Master DP, actually it is as the same as X300 DP PAD, the only difference is the outlook.



Procedure:

  1. Use the two keys to try to turn on the ignition, they are blank new one.
  2. Open X300 DP PAD, go to option:

Immobilizer



Ford

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-02

Immobilizer

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-02

Select car model and year

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-05 ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-06 ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-07

2015-

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-08

Type 1

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-09

All keys lost

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-10

Confugring the systerm, please wait…

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-11

Switch ignition off

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-12

Press Emergency flasher switch

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-13

Open the driver door

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-14

Then close the driver door.

Confugring the systerm, please wait…

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-15

You have to complete the following procedure, engine can be started:

  1. Switch ignition off.
  2. Switch ignition on with key 1 or 3 second and then switch off and remove the key.
  3. Switch ignition on with key 2 or 3 second and then switch off and remove the key.
  4. If you want to add more keys, please repeat procedure 3. complete.

ford-everset-2015-all-keys-lost-key-programming-with-obdstar-x300-dp-pad-16

FORD Everset 2015 all keys lost key programming done with BDSTAR X300 DP PAD.



Tehch support by obdstar engineers.

Have original obdstar X300 DP PAD on the authorized dealer www.uobdii.com.

Tip: the following pictures are green Key Master DP, actually it is as the same as X300 DP PAD, the only difference is the outlook.

OBDSTAR H110 VAG MQB IMMO Cluster tool user manual

OBDSTAR H110 VAG MQB IMMO Cluster tool, 1st in the Chinese market, can work on NEC+24C64 2014- (incl. old models). It also contains a RFID Adapter for VW 4th and 5th IMMO.

OBDSTAR H110 VAG MQB IMMO Cluster tool, 1st in the Chinese market, can work on NEC+24C64  2014- (incl. old models). It also contains a RFID Adapter for VW 4th and 5th IMMO.

Go on reading OBDSTAR H110 user manual including car list and how to use.



OBDSTAR H110 VAG MQB IMMO car list:

(1)2 – 3.5 Generation Immo 17 Dashboard
17 Dashboard
25 Immobiliser
(2)4 Generation Immo
Audi A1:NEC+24C64 2013, 2014.6-
Audi A3/TT/R8(CDC+24C32/3217/3297)
Audi A4 RB4 Audi A4 RB8
Audi Q3: NEC+24C64 2013 Models, 2014.06-
Audi Q7/A6L(C6): 9S12DT(G)128, 9S12DT256
VW/SKODA/SEAT: CDC+24C32
VW/SKODA/SEAT: NEC+24C32
VW/SKODA/SEAT: 2013 Johnson
VW/SKODA/SEAT: Motorola 9S12XHZ512
VW/SKODA/SEAT: NEC   +24C64
VW/SKODA/SEAT: NEC+95320
VW/SKODA/SEAT: NEC+35XX
VW/SKODA/SEAT: Magotan/CC

(3)5 Generation Immo Audi A4L/A5/Q5 Audi A6/A7/A8
VW New Touareg
(4)REMOTE
09 Central control
B5 Central door lock(KWP1281)
46 Central comfort module(kwp1281) 46 Central comfort module(Canbus)
(5)Read PIN
17 Dashboard Jetta Passat Bora
Golf Sharan Polo Lavida 3.5
Sagitar 3.5 2007-, 2006
Touran 3.5
Caddy 3.5
VW 2007-
25 Immobiliser
01 Engine



OBDSTAR H110 VAG MQB cluster calibration car list:

Audi MQB 35XX 2014.06-
Audi A3 2014.06-
Audi Q2 2014.06-
(Note: Continental and VDO dashboard supported only, Chinese Johson and virtual cockpit not supported.)

VW MQB 35XX 2014.06-
GOLF SPORTSVAN 2014.06-
GOLF7 2014.06-
GOLF PASSAT B80 2014.06-
GOLF POLO 2014.06-
Tiguan 2014.06-
Touran 2014.06-
(Note: Continental and VDO dashboard supported only, Chinese Johson and virtual cockpit not supported.)

Skoda MQB 35XX 2014.06-
Skoda Fabia 2014.06-
Skoda Rapid 2014.06-
Skoda Octavia 2014.06-
Skoda Superb 201.06-
(Note : Continental and VDO dashboard supported only, Chinese Johson and virtual cockpit not supported.)

Seat MQB 35XX 2014.06-
Seat IBIZA 2014.06-
Seat TOLEDO 2014.06-
Seat LEON 2014.06-
(Note : Continental and VDO dashboard supported only, Chinese Johson and virtual cockpit not supported.)

For more supported vehicles of immobilizer, please refer to the attachment.

Browse: OBDSTAR H110 VAG MQB cluster calibration car list

OBDSTAR RFID Adapter for VAG 4th 5th IMMO list:

  1. CDC+24C32 Types
  2. NEC+24C32 Types
  3. 2013 Johnson Types;
  4. Motorola 9S12XHZ512 Types;
  5. NEC+24C64 Color Screen- Type 1
  6. NEC+24C64 Color Screen- Type 2
  7. NEC+24C64 White Screen Type
  8. NEC+24C64(VDO -12)Type
  9. NEC+95320 Type
  10. NEC+35XX Type
  11. Magotan/ CC Type
  12. Q7/A6L(C6)9S12DT(G)128 Type
  13. Q7/A6L(C6)9S12DT(G)256 Type
  14. Lifan Marvell models are added, which includes Add/Clear Keys, Program/Delete ESCL functions.
  15. Jiangling MU-X models are added as key programming and key clearing.

How to use OBDSTAR H110 VAG MQB IMMO and cluster calibration tool

Coming soon…

OBDSTAR H110 VAG MQB IMMO and cluster tool Youtube Video

Coming soon…

OBDSTAR H110 VAG MQB IMMO and cluster for sale

http://www.uobdii.com/wholesale/obdstar-h110-vag-immo-and-km-tool-for-mbq.html

obdstar-h110-vag-immo-km-tool-6
