Espace 4 key card used Programming Guide

Car key type: a Espace 4 ph2 with keycard 3 buttons with keyless PCF7936.

Purpose: to program a used key card (Same Buttons and chip). I am trying to learn an used oem key to the car.

Attached the picture. The left one is mine and the right from the other car.

I meant I have the Pin. But only for my car. Not from the other key.

What to do next?

Replace PCF or unlock old PCF, then precode for your car and finally learn to car.


With keydiy KD-X2 or Xhorse mini key tool you can unlock the PCF (the installed transponder) –> Virginize it.
Then you need to create a so called dealer key out of it and learn to your vehicle with renolink. Do you already have the login pin?

When the key is already adapted to another vehicle, you cannot add it to yours. You have to unlock it first. Google “unlock id46 chip Renault”.

Both are very cheap (about 150€) and or only for generating and renewing keys. I own both of them.

I would suggest you to buy the keydiy KD-X2 It has everything on board (renewing cables) and can also clone many transponders 4D/46/48

Both are token free as long as you don’t want to online calculate id48 keys (VAG vehicles).

You can also pay with the collected points.

Which programmer to buy to learn Espace 4 keys to cars?

VVDI2 is only for bmw, vag, Porsche and Peugeot.
If you want to buy from xhorse, buy the the big tablet from them. VVDI Key Tool Plus.
For resetting the transponder you have to solder wires to the pcb. It doesn’t work by remote.

What about VVDI Key Tool Max?


That’s the one I have and it can renew keys but does not come with the cables. You need to buy the renew cables separately.

Why all this trouble about one used key? A new one doesn’t even cost 10€. Where can I buy a new key at 10€?


Image: KEYYOU ID46 PCF7947 Chip for Renault Clio Logan Megane 2 3 Scenic Remote Key 3 Buttons 433Mhz Smart Card Emergency Insert

Good to know:

7936 is only the basic ID46 transponder without any remote information. PCF794x only means that remote information of the central locking system is also stored in the transponder chip alongside with the anti-theft system. These transponders never belong to a single vehicle model or even brand. When you look for pcf7947 in aliexpress you will finde hundreds of vehicles using that specific id46 transponder type.

So you received a lot of information and device suggestions. Now you have to get your stuff sorted and decide how you want to proceed with your key adding challenge. Any locksmith with proper tools would do job for under 90€ within 20 min.

Xhorse VVDI Audi locked BCM2 Solution

Xhorse BCM2 Solder-Free Adapter Set is designed for Audi Add Key and All Key Lost Solution without connecting to Audi Server. You can program a key with a regular 754J key on the aftermarket instead of special key.


Xhorse BCM2 Solder-Free Adapter works with:

VVDI Key Tool Pad Plus

VVDI2+VVDI PROG (Use VVDI Prog to read BCM2 data)

Xhorse BCM2 Solder-Free Adapter support list:

  1. 2013-2019 A4L, A5, Q5

(BCM2 version: 0711, 0650, 0641) Support add key and all key lost

  1. 2013-2019 A6L, A7, A8

(BCM2 version: 0825, 0824, 0827) Support get BCM2 immo data when all key lost

Add Key All Keys Lost
Read BCM2 data Sync data Read BCM2 data Sync data
A4L/A5/Q5 -2013 OBD No OBD/some need remove BCM2 No
A4L/A5/Q5 2013-2019 Xhorse BCM2 Adapter No VVDI BCM2 adapter No
A6L/A7/A8 -2013 OBD Obtain from working key OBD/some need remove BCM2 Obtain from third party
A6L/A7/A 2013-2019 OBD Obtain from working key VVDI BCM2 adapter Obtain from third party

VW BCM2 Solder-Free Adapter Update:

It is free update online as other Xhorse tools, no need tokens.

How to use Xhorse BCM2 Solder-Free Adapter with VVDI Key Tool Plus?

VVDI Add key & all key lost solution for Audi solder-free adapter set.

remove the BCM module from an Audi car.

xhorse-bcm2-solder-free-adapter-02 xhorse-bcm2-solder-free-adapter-03

Connect the Audi solder-free adapter set to a VVDI Key Tool Plus.

xhorse-bcm2-solder-free-adapter-04 xhorse-bcm2-solder-free-adapter-05

Add new key or program key when all keys lost for Audi with VVDI Key Tool Plus, just follow the on-screen guide to do until succeed.

Then, re-install the BCM2 module to the car.


Don’t you think Xhorse BCM2 Solder-Free Adapter make Audi key programming job easy. Pre-order one at only 100usd at now.

Lonsdor K518 AKL programming under alarm state for Land Rover / Jaguar

Lonsdor K518 JLR super update AKL programming under alarm state for 2015 – 2018 Land Rover & Jaguar. Is the JLR License available for all software versions of FK72 HPLA?

The answer is:

For FK72 all keys lost, you can directly use Lonsdor specific key to program via OBD;

In another word, need extra: JLR License + Lonsdor specific key.



For HPLA all keys lost, Lonsdor k518 can program via OBD with specific JLR connector.

In another word, for HPLA all keys lost, need extra: JLR License + Lonsdor specific key+ Lonsdor JLR connector.


Good to know:

Lonsdor JLR License: Please provide the machine serial number to activate, no need shipping. JLR license is permanent, won’t be expired.

Here is the guide on FK72 all keys lost key programming with Lonsdor K518

Car model and year: 2017 Jaguar XFL AKL in alarm state version.

Open the car door, the buzzer keeps beeping, car is in alarm state.

Prepare Lonsdor Smart Key 315MHz/ 433MHz (above mentioned) and the unlocked key previously programmed on current car, confirm they don’t work before testing.

Tap [All smart key Lost ] -Yes -> No (all keys lost and not original key) -> Yes (to generate key by following the AKL procedure.


Key position [01] generate key – select Lonsdor specific key for Jaguar Land Rover.

Put the specific key (to be programmed) into K518 card slot.

Tick off “Lonsdor dedicated Jaguar /Land Rover key” and tap “Yes” to go on.

Keep the key placed stably, until the 1st key is generated successfully.


After generating the 1st key, press the remote’s unlock button to disarm car alarm state.


Key position [02] generate key – select the unlocked key previously programmed on current car.

Put the specific key (to be programmed) into K518 card slot.


Tick off ” The current vehicle has been matched with the unlocked original factory or the aftermarket key ” and tap “Yes” to go on.


Failed to generate, because the key was not placed properly, please adjust the key position, retry to generate working key.


The 2nd key is generated successfully.


Lonsdor K518 Program 2017 Jaguar XFL AKL successfully, please back to the home menu.

Next is to test if the two keys’ remote / smart start function work fine.



Tool Recommendations for Truck Immo All keys lost

Recommend good tools for trucks Immo / All keys lost, particularly Euro trucks – Benz, Scania, Volvo.

There is no universal tool that will do all. I do repairs on all european truck excluding Iveco, and I can share some experience if it comes to immo.

MAN – Any tool to read/write by E-GPT protocols or by BDM (EDC7) or Boot (EDC17 Euro 6) will be okay for engine ECU, and You would need EEPROM programmer and Macaca for FFR/PTM (FFR only EEPROM). With such tool You will be able to disable the immo (but I’m not sure if there is any Immo off option for EDC17 currently). Or You can get MANCATS II and III with developer software and You will be able to programm keys in truck to about 2016 year production. Newer are blocked and harder to bypass.

Volvo/Renault – Get Vocom with PTT, You can easily disable Immo in V2 trucks, change two parameters and You have no Immo and no error on dash. Fast and easy. For V4 trucks, never had to learn yet, as there was no client that needed new keys, so can’t tell much. But PTT will let You disable the Steering Lock that tend to fail on those trucks very often.


DAF – Euro 5 DMCI, Get Davie XDCII with DAF MUX-560, You can program keys, change ECUS, change Immo boxes no problem. For Euro 6, Davie will be ok up to 2016. Newer only Davie 4, but if You’re not authorized DAF Dealer, no Immobilizer programming. It’s totally blocked.

Scania – Get VCI3, install SDP3 and XCOM. Learn how to modify SOPS files and erase Immo with XCOM, and You’re good to go with S6 and S7 Ecus. With S8/EMD1 it’s more complicated but doable. With SDP3 You can teach new keys, delete old ones and with few tweaks to SOPS files, You can also disable the Immo. Still, EMS and COO need to be paired, but it’s easy procedure with SDP3.

So… A lot of money to invest if You want to do every brand. If You want to start cheap – go for Scania. VCI3 is quite cheap, all the necessary software You can find on forum (or bought reliable source sdp3 software). MAN and DAF have the most expensive interfaces right now. There is no do-it-all software, like the ones for cars, that will let You program everything unfortunately.

euro-trucks-immo-all-keys-lost-tools-02 euro-trucks-immo-all-keys-lost-tools-03

Good luck!

2020 Top 4 BMW Key Programming Tools Review

Put together all the best buy for BMW key programming tools based on real users’ reviews, incl. yanhua mini acdp BMW, vvdi2 for BMW, Autohex, Autel IM608 etc.

1.Yanhua mini acdp BMW


I am using yanhua mini acdp. Tested very much times, never failed for me. Very comfy to work from phone, now I always read eeproms by yanhua just from phone.

And with yanhua 0 soldering. Even though it’s easy to folder to cas, it still takes 3min. With yanhua its 30 sec.

2. VVDI2 for BMW

1)  I use vvdi2 for BMW and used to remove eeprom off the board to read, until i had an accident with one!
Have since been reading in circuit using vvdi prog and dropping Vcc down to 3.3v for reading.
So far so good…

2) I have VVDI2 and use this for BMW FEM keys. I was desoldering 95128 chip from FEM and had an accident with one. Managed to get it sorted in the end when someone with Autohex unlocked a used FEM (without key) for me.

I still used my VVDI2 but read the 95128 in circuit using VVDI Prog (dropped the Vcc down to 3.3v) and even Carprog original (again read at 3.3v), read multiple times, verify and compare files. Everything went fine.
It was so much easier and quicker.

3) I have VVDI2 but I used it only once on Mini to read ECU EDC1722 ISN by OBD because autohex fail to read it.
2 days ago I programmed F30 AKL without desoldering with autohex

4) Last week I did F20 akl without desoldering with VVDI2

 3.Autohex for BMW


1) Depends how many BMW you do. Autohex works great on them but its not cheap.

2) Autohex it’s a good tool to invest!
I don’t use it much but I know if something goes wrong autohex will save my assess?

3) If you have only locksmith version and you try to program petrol CAS3+ with Continental ECU by OBD you will be very surprised

4) I’ve started with Autohex II BMW Lite Locksmit  but been forced to update to AutohexII BMW Full Version.
If don’t have full, it’s a bit useless!

5) E70 AKL is the same! Cannot be done even if they are saying “all e and f series”.
Also fem/bdc, 99% of them need update before unlock. Can be done from advanced functions but not always!

But worth having full!
Many BMW on the road and are not the best cars..


Good think about AH – it will notify you when clip is not connected. You won’t go any further without that. I use AH a lot and since 2 years now never fail on me so far.
Only bad but I can say is CAS4. You won’t do even spare key with OBD if you don’t have ISN.

4. Autel IM608


I bought im608 few weeks back..
So I’m testing this tool on bmw..
It has a lot functions…so I’m testing as I go…
Waiting on for the g-box2 couse cant work on bench without it…
Trying to read ISN on edc17c06 by obd ..cas3+..
Cas ok but it takes long for ecu to read isn so im not sure does it work or is just take longer…

More operation guide on Autel IM608 BMW(CAS1/CAS2/CAS3/CAS4/FEM/BDC)

To be upgrading…

Thanks to all users of DK forum.

How to install CGDI MB Key Programmer Software

CGDI MB software install guide and Introduction.

Step-by-step guide:

Step 1: Free download CGDI MB software

Download:  CG-MB BenzMonster V3.0.1.0

Select the latest CGDI MB software (BenzMonster_xxx_Setup.exe), double click it to download


Step 2: Install CGDI MB software

After download, double click the CGDI MB application to install (The newest software is v3.0.1.1 so far)

Tips: It is recommended that you close all other applications before starting setup. This will make it possible to update relevant system files without having to reboot your computer.


Step 3: Run CGDI MB software

Open CGMB software

Select the language you desire (English, Spanish, French, German, Russian, Turkish and Chinese)

Then follow the guide to understand the basic functions of the software.


Device information:

When the CGDI prog MB is ready, you can see the current device level, points (yellow circle icon), the number of password calculation remaining today (red diamond qty), the number of key files generation remaining today (green diamond qty) and subscription service remaining days (dots icon).

Points and subscription services can be purchased at the online store.


Personal account:

Click the button to open the personal account window, and you can sign in, view your account info and CGDI MB programmer bound.

If you don’t have a personal account, you can create one.


Connect CGDI mb prog with computer

If this is your first time to use, please sign up with username, password, name, phone number and email.

If you already have an account, just sign in directly.


Please follow the guide to activate new cgdi mb.


You can send feedback, visit the customer service center, and view the update log.

Besides that, you can also perform a self-test of the simulated key, upgrade the firmware, switch language and view information.


-Feedback: please offer the problems what happened with words and log or screenhot, and write SN and contact info (WhatsApp account or email)


-Analog key self-test: here you can test OBD voltage, cgdi prog mb coil power supply, reception and sent.



Option, wiring diagram, online store, key points and tutorial are provided here.


Wiring diagram and tutorial can help you use the software.

cgdi-mb-instruction-11 cgdi-mb-instruction-12

If you need to recharge points or renew the service, you can go to the Online Store to buy.

The point also can be redeemed.


Function Toggle:

Here you can perform these functions:


Compute password

Read/write key

Generate key file

Auto computer


Mileage repair


Main function area:

This is the main function info display and operation area.

The prompt message and progress will be displayed below, please pay attention.


Status bar:

At the bottom of screen, you can see the device status, technical support contact info and version info.

When a new version is available, a prompt message will displayed here.


User Wizard Completed

Infrared diode hardware upgrade:

It’s very hard to read the keylessgo keys and sometimes will fail to register other keys.

So recommend to change the black accessory to red one. This is free of charge.

Click CGDI MB Infrared diode operating instructions to know details.

CGDI MB More Details:  CGDI prog MB Benz key programmer

Obdstar Key Programmer Upgrade of June 2020

newest update on June 2020, The update including key programming, Mileage Programming,Oil Service Resetting,Optimization and Tablet Display Program Software.

Obdstar Tablet Key Programmer includes: Obdstar X300DP Plus Pad2, Obdstar X300 Pro3 key master, Obdstar X300 DP Pad key master


Obdstar Tablet Key Programmer Update details on June 2020:



1. Increased CAS1/CAS2 IMMO Data( Help Info) V10.01

2. Increased CAS3 IMMO Data( Help Info) V10.01

3. Increased German V30.37

4. Optimized the FEM/BDC Document ID V10.01

5. Optimized CAS2 immo data V30.37

6. Optimized FEM/BDC enable key function V30.37


1. Increased new IMMO Data(help info) for Benz software V10.00


1. Optimized Karry K50 electrocar_remote system V30.45

2. Optimized Chery_Tiggo5_remote system V30.45

3. Optimized IMMO system_Chery auto immo system_Engine ECU program V30.45

4. Optimized smart key system_Tiggo8_Ariza 7E_Type2 (pincode free) V30.45

5. Optimized Chery Tiggo8_Type2_ (pincode necessary) V30.45


1. Optimized Software of Peugeot 408 T7 immo system V32.34

2. Optimized Software of 2006 Peugeot 406 pincode reading V32.34

3. Increased German V32.34

4.  Increased help info (doc.) V10.00


1. Increased GRAND VOYAGER 2018,2019 smart key programming (Pincode free) V33.04

2. Increased tips for Jeep Renegade 2015-2017(Beta) V33.05

3. Optimized Software of 2011 Wrangler original key programming V33.04

4. Optimized Chrysler IMMO Menu, correct and Increased help info for some cars V10.01

5. Optimized Jeep_RENEGADE_IMMO_2015-2017(Beta)_Making dealer key function V33.06

6. Optimized Jeep_GRAND-CHEROKEE_2018-2019_Smart Key Programming V33.06


1. Increased IMMO Data( Help Info) V10.00


1. Increased CF, LF, XF 2006- BLADE V30.00


1. Increased ALFAROMEO 159(1K79X ID46 eeprom) V32.46

2. Increased Tips for DELPHI 70F3556(MQB/Megamos AES)  V32.46


1. Increased 2020 Escape Smart key New Type V34.06

2. Optimized FUSION_USA_BLADE_2013-2019 all key lost Software V34.05

3. Optimized Ecosport_ -2017_Type 1_ Immo system V34.05

4. Optimized Ecosport_ -2017_Type 2_ Immo system V34.05

5. Optimized Software of New Focus after 2014 V34.05

6. Optimized 2015- EXPLORER smart key function V34.06

7. Optimized FOCUS_EUROPE_BLADE_2005-2011_TYPE 1 key programming function V34.06

8. Optimized IMMO System_Classic Focus_ -2011_Auto detect_Synchronize engine and immo V34.06

9. Optimized Mustang 2015-2017 Software all keys lost function, Increased function of delete keys V34.06

10. Optimized Mondeo _Proximity_Type 1 software V34.07

11. Optimized TRANSIT_EUROPE_BLADE_2014-2016_Add Key software V34.07

12. Optimized Territory 2019 IMMO System V34.07

13. Optimized EDGE 2017-_Smart Key system_All keys lost function V34.07


1. Increased GL8_With Smart_ 2019- (after 2019) V32.11

2. Increased Chevrolet LOVA and SPARK under African Area V32.12

3. Increased Cadillac Europe_BLS_Smart key system; American XT4, XT5 and XT6 Smart key system V32.12

4. Optimized Buick_GL6_With Smart_2017-, Buick_GL6_Without Smart_2017- Software V32.11

5. Optimized Software of EXCELLE_-2012_Remote Programming V32.11

6. Optimized Software of ENVISION -2017 V32.11

7. Optimized Software of MALIBU_With Smart_ -2016 key programming V32.11

8. Optimized Software of REGAL_With Smart_-2016_Type1_All Smart Key Lost V32.11

9. Optimized Buick GL8_2017-_2.0T_With Smart (No need the 10 digit auth-code) V32.12

10. Optimized Chevrolet EPICA 2013 Remote Programming software V32.12


1. Increased Greatwall H6-COUPE 2017- Smart Key System V31.77

2. Increased Greatwall CH041E Body Control System V31.77

3. Increased Haval M1 STEC IMMO System V31.77

4. Increased Haval M2 DIAS IMMO System V31.77

5. Increased Haval M4 STEC IMMO System V31.77

6. Increased Wingle7 Delphi Diesel(Delphi 4D20) IMMO System V31.77

7. Optimized GreatWall ORA R1 Smart Key System V31.77

8. Optimized GreatWall C30 Engine programming function V31.77

9. Optimized GreatWall VV6_2017-_Smart Key System V31.77

10. Optimized Haval F5_Smart Key System V31.77

11. Optimized Haval H6_2013-2018_Smart Key System_Kstar Knob PEPS system_Replace EMS V31.77

12. Optimized Haval H6 Kstar Knob PEPS system_Replace EMS V31.77

13. Optimized Haval H5_IMMO System_ Delphi Diesel(Delphi 4D20) IMMO System_key programming V31.77

14. Optimized Haval H2S_Smart Key System V31.77



1. Increased German V30.31

2. Increased help data for “make start keys”(smart key after 2015) function V10.01

3. Increased Immo data for X-TYPE V10.01 (Documents)

4. Optimized the tips V10.01 (Documents)

5. Optimized XF 2013- Smart key programming process V30.32


1. Optimized JAC_iEV7s_smart key system V30.46

2. Optimized JAC_Refine M5_Remote System_16PIN V30.46


1. Increased YU SHENG S330 Hui Chuang Immo system V30.23

2. Increased Pickup_Baodian_Remote_Manual Method V30.23

3. Increased Light Truck_N806_Tungthih BCM V30.23

4. Increased German V30.23

5. Optimized Yu Sheng S330 Smart key and S350 Smart key Pincode free system V30.23


1. Increased K5(DL3A) BLADE,REMOTE,PROXIMITY V31.01 V31.00

2. Increased OPTIMA(JFA) 2019- BLADE,REMOTE,PROXIMITY V31.01 V31.00

3. Increased TELLURIDE(ON) 2018- BLADE,REMOTE,PROXIMITY V31.01 V31.00

4. Increased FORTE(BD) 2020- BLADE,REMOTE,PROXIMITY V31.01 V31.00

5. Increased K9(RJ) 2019- BLADE,REMOTE,PROXIMITY V31.01 V31.00

6. Increased NIRO(DE EV) 2019- BLADE,REMOTE,PROXIMITY V31.01 V31.00

7. Increased NIRO(DE HEV) 2019- BLADE,REMOTE,PROXIMITY V31.01 V31.00

8. Increased NIRO(DE PHEV) 2017-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

9. Increased SELTOS(SP2) 2020- BLADE,REMOTE,PROXIMITY V31.01 V31.00

10. Increased SOUL EV(SK3 EV) 2019- BLADE,REMOTE,PROXIMITY V31.01 V31.00

11. Increased SOUL(SK3) 2020- BLADE,REMOTE,PROXIMITY V31.01 V31.00

12. Increased STINGER(CK) 2018- BLADE,REMOTE,PROXIMITY V31.01 V31.00

13. Increased FORTE(BDM) 2019- BLADE,REMOTE,PROXIMITY V31.01 V31.00

14. Increased BONGO3(PU11) 2004-2016 BLADE,REMOTE V31.00

15. Increased BONGO3-COACH(PU21) 2004-2007 BLADE,REMOTE V31.00

16. Increased BONGO3-TRUCK(PU11) 2008-2018 BLADE,REMOTE V31.00

17. Increased BONGO3-TRUCK(PU11) 2004-2007 BLADE,REMOTE V31.00

18. Increased CARENS(RP) 2017-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

19. Increased CARNIVAL(YP) 2015-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

20. Increased CARENS2/EXTRA(RS) 2002-2006 BLADE,REMOTE V31.00

21. Increased CARENS2/X-TREK(RS) 2002-2006 BLADE,REMOTE V31.00

22. Increased FORTE HEV(TD HEV) 2010-2013  BLADE,REMOTE,PROXIMITY V31.01 V31.00

23. Increased FORTE HEV(TF HEV) 2010-2013 BLADE,REMOTE,PROXIMITY V31.01 V31.00

24. Increased K3(BD) 2018-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

25. Increased K5 PHEV(JF PHEV) 2016-2019 PROXIMITY V31.01 V31.00

26. Increased MOHAVE(HM) 2017-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

27. Increased MORNING(JA) 2017-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

28. Increased PRIDE 2005-2019 BLADE,REMOTE,PROXIMITY V31.01 V31.00

29. Increased GRAND CARNIVAL 2015- BLADE TYPE 2 V31.00

30. Optimized smart key pincode reading function V31.00


1. Increased German V31.13

2. Optimized Software of 2012 Discovery 4 V31.13

3. Optimized Evoque -2013 Smart key programming V31.14


1. Optimized MAZDA 3_Type 5(Axela)(2018-) Smart key Software V30.69

2. Optimized MAZDA 3_Type 2_All keys lost Software V30.69


1. Optimized 2010 Nissan Tiida the problem of long-stay on same page when program the Remote V31.88

2. Optimized Nissan one-key smart key system with 4digit pins V31.88

3. Optimized knob key programming of 2010 Nissan Tiida V31.88

4. Increased German V31.88

5. Increased Nissan Juke Europe 2010- smart key system V31.88


7. Optimized Nissan_ 4 PIN _ Remote _ Type 1 V32.00

8. Increased 20 digital pincode_proximity_manual select system_type 5 V32.00


1. Increased German and other languages V31.32

2. Optimized the menu “select from vehicle” V31.32

3. Optimized “Select from Type_Smart key system_Type 1_Increased key” function V31.32


1. Increased ACCENT 2018-2019 PROXIMITY V31.01

2. Increased ALSAN(AG) 2015-2018 PROXIMITY V31.01

3. Increased AVANTE 2009-2019 BLADE ,REMOTE ,PROXIMITY V31.01

4. Increased AVANTE COUPE(JK) 2013-2016 BLADE ,REMOTE ,PROXIMITY V31.01

5. Increased AVANTE HEV(HD HEV) 2010-2014 BLADE ,REMOTE ,PROXIMITY V31.01


7. Increased AZERA 2012-2017 BLADE ,REMOTE V31.01

8. Increased BLUE ONE(EAEV) 2011 REMOTE V31.01

9. Increased ELANTRA 2019- BLADE ,REMOTE ,PROXIMITY V31.01

10. Increased ELANTRA GT(PD) 2018- BLADE ,REMOTE ,PROXIMITY V31.01


12. Increased ENTOURAGE(EP) 2007-2010 BLADE ,REMOTE V31.01

13. Increased EQ900(HI) 2016-2018 PROXIMITY V31.01

14. Increased G70(IK) 2019- BLADE ,REMOTE ,PROXIMITY V31.01

15. Increased G90(HI) 2018- BLADE ,REMOTE ,PROXIMITY V31.01

16. Increased GENESIS COUPE 2010- PROXIMITY V31.01

17. Increased GRAND STAREX(TQ) 2008-2019 BLADE ,REMOTE ,PROXIMITY V31.01

18. Increased GRANDEUR HEV(HG HEV) 2014-2016 PROXIMITY V31.01

19. Increased GRANDEUR HYBRID 2014-2019 PROXIMITY V31.01

20. Increased GRANDEUR(IG) 2017-2019 BLADE ,REMOTE ,PROXIMITY V31.01

21. Increased GRANDEUR(TG) 2005-2011 BLADE ,REMOTE ,PROXIMITY V31.01

22. Increased I30 2017-2018 BLADE ,REMOTE ,PROXIMITY V31.01

23. Increased I40(VF) 2016-2019 BLADE ,REMOTE ,PROXIMITY V31.01



26. Increased IONIQ PHEV(AE PHEV) 2017-2018 BLADE ,REMOTE ,PROXIMITY V31.01


28. Increased IONIQ PLUG-IN(AE PHEV) 2017-2019 BLADE ,REMOTE ,PROXIMITY V31.01

29. Increased KONA ELECTRIC(OS EV) 2019- PROXIMITY V31.01

30. Increased KONA(OS) 2019- BLADE ,REMOTE ,PROXIMITY V31.01

31. Increased LAVITA(FC) 2001-2007 BLADE ,REMOTE V31.01

32. Increased LIBERO(SR) 2006-2009 BLADE ,REMOTE V31.01

33. Increased MAXCRUZ(NC) 2014-2019 BLADE ,REMOTE ,PROXIMITY V31.01

34. Increased NEXO(FE) 2018- BLADE ,REMOTE ,PROXIMITY V31.01

35. Increased PALISADE(LX2) 2018- BLADE ,REMOTE ,PROXIMITY V31.01

36. Increased POTER2(HR) 2004-2019  BLADE V31.01

37. Increased SANTAFE 2019- BLADE ,REMOTE ,PROXIMITY V31.01

38. Increased SANTAFE SPORT 2017-2018 REMOTE V31.01

39. Increased SOLATI(EU) 2015-2018 BLADE V31.01

40. Increased SONATA 2020- BLADE ,REMOTE ,PROXIMITY V31.01

41. Increased SONATA 2015-2019 REMOTE TYPE2 V31.01

42. Increased SONATA HEV(LF HEV) 2016-2019 PROXIMITY V31.01

43. Increased SONATA HYBRID 2011-2015 BLADE ,REMOTE V31.01

44. Increased SONATA PHEV(LF PHEV) 2016-2017 PROXIMITY V31.01

45. Increased SONATA PLUG-IN HYBRID(LF PHEV) 2016-2019 PROXIMITY V31.01

46. Increased SONATA PLUG-IN(LF PHEV) 2016-2019 PROXIMITY V31.01

47. Increased TUCSON FCEV(LM FCEV) 2015-2017 PROXIMITY V31.01

48. Increased TUCSON FUEL CELL(LM FCEV) 2015-2017 PROXIMITY V31.01

49. Increased TUCSON IX FUEL CELL(LM FCEV) 2015-2017 PROXIMITY V31.01

50. Increased TUCSON IX(LM) 2004-2015 BLADE ,REMOTE ,PROXIMITY V31.01

51. Increased TUSCANI(GK) 2001-2009 REMOTE ,PROXIMITY V31.01

52. Increased VELOSTER 2019- BLADE ,REMOTE ,PROXIMITY V31.01

53. Increased VELOSTER N(JSN) 2019- PROXIMITY V31.01

54. Increased VENUE(QX) 2020- BLADE ,REMOTE ,PROXIMITY V31.01

55. Increased VERACRUZ(EN) 2013-2016 BLADE ,REMOTE ,PROXIMITY V31.01

56. Increased VERNA HEV(MC HEV) 2005-2009 BLADE ,REMOTE V31.01

57. Increased VERNA HYBRID(MC HEV) 2005-2009 BLADE ,REMOTE V31.01


59. Optimized 2012 Shengda_47 smart key pincode reading V31.01

60. Optimized 2019 Elantra_smart key system V31.01

61. Optimized Manual select_IMMO_Type 1 V31.01

62. Optimized the menu V31.01


1. Increased German V30.46

2. Optimized Opel 2007 ZAFIRA-B key programming procedures V30.46


1. Increased IMMO Data( Help Info) V10.11

2. Optimized help info of KADJAR, CLIO(2016-2019)

3. Optimized the Help Info V10.12


1. Increased German language V30.31

2. Optimized Rexton (gasoline) IMMO System V30.31


1. Optimized E100_Remote system V30.46

2. Optimized 560_Smart key system_Increased keys V30.46


1. Increased German V30.64


1. Increased German and other languages V32.22

2. Increased the menu of Smart key system_Type 2(Crown of 2012)_Clear Smart Key V32.23

3. Optimized smart key system – type 7(2020) V32.22

4. Optimized Lexus RX270 smart key system V32.22

5. Optimized Smart key system_Type 2(Crown of 2012)_Add Smart Key V32.23

6. Optimized IMMO System_Type1 (67/68)_Immo reset software V32.23


1. Increased Vietnamese, Hebrew and German V30.10


1, Increased new RFID software V34.48

Cluster Calibration


1. Increased ALFA MITO Cluster Calibration V30.12


1. Increased Help Info V10.00


1. Increased tips of FCA Converter for cars after 2018 V30.47


1. Optimized Software of KIA K5 D70F3423 V30.99

2. Optimized Software of KIA CEED NEC after 2011 V30.99


1. Increased Maserati Quattroporte 2005-2006 Cluster Calibration V30.08


1. Increased ESCAPE V DASH(VISTEON),ABS Cluster Calibration function V30.86

2. Increased KADJAR DASH(VISTEON),ABS Cluster Calibration function V30.86

3. Increased MEGANE IV DASH(VISTEON),ABS Cluster Calibration function V30.86

4. Increased SCENIC IV DASH(VISTEON),ABS Cluster Calibration function V30.86

5. Optimized KADJAR software V30.86

6. Optimized Captur software V30.86


1. Optimized the help info and layout for Citroen/Peugeot V10.01

2. Optimized C4 Software V31.18

3. Optimized 301 Software V31.18

4. Optimized BSI EOX V31.18


1, Optimized the menu and Increased tips of FCA Converter for cars after 2018


1. Optimized VW K LINE Software

2. Optimized VW NEC35XX Software

3. Optimized AUDI A6L 2012- Software

Oil Service Reset

New Increased:

1. Junma series oil reset function  V32.23

2. Manuel reset  V32.23


Citroen: C4 AIRCROSS

SAIC MAXUS:D90,G10,G20,G50,T60


New Baojun: RS-5

Qoros: Qoros 5


3. Aston Martin and Maserati FCA help info  V32.23

4. Chrysler/Jeep/Dodge auto reset to zero, and FCA help info for cars after 2018 V32.23

5. Changhe Q7 and Beiqi BJ40 oil reset function  V32.23

6. GreatWall Fengjun 5,VV6 and P8 oil reset function  V32.23


1. Rework on the Greatwall series, modified the menu and software structure  V32.23

2. Optimized Manual reset for cars  V32.23:


Ford: Wing Tiger;



Roewe: 350, 950.

3. Optimized Benz menu and the tips  V32.23

4. Put Ford, Mercury, Lincoln at the same menu  V32.23

5. Modified part of the name with manual reset to zero function under Chrysler/Dodge/Jeep  V32.23

6. Capitalized the name of some brands  V32.23

7. Delete some Chinese brands  V32.23

8. Optimized Benz models as:298,290,205,257,238,213,293,253,222;  V32.23

9. Modified the auto reset to zero function of VW CAN protocol and Bosch protocol  V32.23

7. Increased Dongfeng Nissan, Zhengzhou Nissan, China Toyota, China Ford manual reset

8. Increased Ford Messenger,Motorhome/Removable Chassis Van, E-series shuttle bus manual reset

9. Increased Chrysler Grand Caravan/300/Poplar, Dodge Ram/Dodge Nitro/Dodge Dakota manual reset

10. Increased Mercedes-Benz and Smart VIN code auto select

11. Increased Besturn X40 2018 white screen auto reset

12. Optimized BMW auto reset

13. Optimized the Porsche menu

14. Optimized 2018 Cayenne and Panamera oil service rest

15. Optimized Roewe EI6/ERX5/I6/RX3/RX5 oil service reset

16. Optimized 2018 Cadillac XT5 and 2017 Geely Borui oil service reset

17. Increased new models of Geely: BINRUI, BINYUE, BORUI GE, DIHAO GL PHEV, DIHAO GSE, DIHAO NEW PHEV V32.24

18. Increased Manual Reset for Toyota Carola, Honda XRV, BYD Song Pro V32.24

19. Optimized the menu by Areas V32.24

20. Optimized Benz software V32.24

Tablet Display Program Software

Increased the German language

Obdstar key programmer update history:  Obdstar Update


Top 11 car key programmers – review and shopping guide [2020]

We are car key programmers authorized dealer,  we deal with the best key programmer for many years, and it makes me always a lot of thinking about getting something or not, that’s why I wrote this post. I will try to tell what kind of key programmers we have, and what they are good for, based on an increasing number of users’ feedback and our sales data.

Key programmers:

Tango (from Scorpio-Lk or clone)
Microtronik Autohex II key programmer
obdstar (X300 DP Plus, x300 pro4)
Lonsdor K518ISE + SK-LT
Autel MaxiIM IM608, Autel MaxiIM IM508
Yanhua Mini ACDP
Xtool (X100 Pro2, X100 Pad2)
SVDI 2020 & SVDI 2018
Autek IKey820

Top 1: Scorpio-Lk Tango & clone Tango


Scorpio-Lk Tango V1.115 highlights:

TangoPlus Subaru Smart Key (Page1 F1, F3) Systems OBD framework

Toyota-H Immobilizer All Keys Lost solution (Gen1 MCU 11910 & Gen2 MCU 12xxx) – Tango + Barracuda (all markets)

Toyota-H Immobilizer All Keys Lost solution (Gen1 MCU 11910) – SLK-06 (all markets)

Cloning of Toyota H-key [Blade](128bit) on LKP-04

Toyota/Lexus Smart Key Systems OBD Framework

Toyota G Immobilizers OBD Reset & Add Key (including EU type)

Toyota/Lexus H Keys Image Generation Page1 39, 59, 5A, 99, 3A, 7A on TRPWS21 transponder

Toyota/Lexus G Keys Image Generation and Clonning Page1 19,36,56,96,37,57 on LKP-02,CN5

Toyota/Lexus/Subaru SmartKey Reset (40/80/128bit)

FREE Off-line Full Copy of TIRIS DST (ID60-70) onto TPX2,EH2,CN2,CN5,LKP-02

FREE Image generator ID70 on ID4D

Image generator ID67/68 on ID4D

Full FREE production of TP22, TP23, TP24, TP25

Free write Component Security 7 bytes Tool (Megamos48)

Over 1142 Key Makers, 793 included with basic software

In-depth Manual and Technical Support Provided

Searching of the 7th byte by existing car’s key(Megamos48)

Scorpio-Lk Tango Pros:

1). 100% Original Scorpio-LK Tango
2). Free update online
3). Latest Version: V1.115
4). Supports Daihatsu G Chip Function (Need to pay)
5). After generating a new transponder with TANGO Programmer, you will not need any additional diagnostic equipment to program the generated transponder to the car! It will start the car directly, even on new FIAT CODE 2 system, also used in PSA Group vehicles! Only you have to write the new file back into the immobilizer system!
6). With Free TANGO OBD Cable.

7). No token limitation.

8). You can check Tango user manual in the menu after software installation

9). you can buy extra modules from Skorpio-LK no problems

Scorpio-Lk Tango Cons:

1). Failed: I reprogram a BMW key, I can’t delete the reprogrammed key with Tango.

2). To have Scorpio-Lk Tango full Autho, it is not cheap.

Scorpio-Lk Tango using tips:

1). Connect TANGO to computer with internet, start the software to [help]>>[check update], then you can update Tango to latest software.
2). Please visit Tango official website and update within 28 days, or it will get locked
3). If you want to get authorization for special functions or cars, please refer to official website too
4). If your Tango already get G chip authorization, it can only generate G chip 10 times per day.

Scorpio-Lk Tango –  a must have key programmer

It is modular like AVDI or TMProII, with limited free functionality for each manufacturers. The whole BMW package is free, so you have to get it if you have to deal with Beemers. To be honest it has lots of weak points, but the documentation what is included makes it worth to pay for: pictures of the devices what you have to look for, sometimes with location and unmount pics; list of the transponders what you can use to the chosen task; the name of the chip what you have to deal with. Packages are from 50€, you get the activation code in e-mail very fast, but can depend on your dealer. So much from the good side, let’s see the weak points: It comes often, that you can’t open the .bin files for their name, just have to find out where the program accepts it. For example: Yaris as Corolla, Insignia as Camaro, Cordoba as Polo, Picanto as C’eed, aso. It gives some well-known problems: can’t do anything with the RB8 controllers, also. It is a bit uncommon, that it wants to be updated always, but who cares, it goes fast enough via smart phone too.
However: you have to buy this to be able to do your work, so take a deep breath, and pay: 959 dollars for the basic sw + hw.

Clone Tango

Firmware Version : V4.8

Software Version:  V1.111

Supported Languages: English.

Clone Tango Pros:

AD100 Out – In codes 8 digits calculator

BMW CAS Keyless Go key maker

BMW CAS remote key maker

BMW CAS unlock and write locked with unknown password  transponders PCF7943&PCF7944 key maker

BMW bikes (Hi Tag 2) Key maker

DAF key maker

KESSY (Hi Tag 2) Audi , Bentley, Porshe, VW key maker

New AUDI A6/Q7 EZS (Megamos 8E) Key maker

VW Key maker

FREE Off-line Full Copy of TIRIS DST (ID60-70) onto TPX2,EH2

FREE Image generator ID70 on ID4D

Image generator ID67/68 on ID4D

Full FREE production of TP22, TP23, TP24, TP25

Clone Tango Cons:

It has many bugs and sometimes goes faulty for no reason:
I have tried new Fly tango V1.111, it does not work. Before update it worked little bit. For example I could red Skoda 1998 iD33 key. But after update nothing works. Except for documentation, that works. I am using it on windows XP, no yellow flags. When I check Fly tango software says everything is ok, but last line says some errors. I think I have to buy original Tango.

Top 2: Microtronik Autohex II key programmer


Autohex II Diagnostic Scan Tool has been designed to be you own technical assistant, especially in BMW cars where things were stuck before Autohex II be in market.
Now, Ecu programming and coding, Ecu replacment (including DME/DDE, CAS, FEM, BDC, EGS,…etc), Key Programming, Manual coding, and many other advanced functions became so easy and safe with our new software interface and online services.

Autohex II BMW Software

Autohex II BMW Diagnostic Tool with the help of HTag Pro key programmer is the best solution for those who are looking for a single diagnostic tool that solves all cases in BMW key programming in both E and F series.

Using the equipped functions of key programming, you can read, write, block, unblock, save and delete any key in the CAS.

Autohex II BMW Scan Tool has an advanced functions for Encrypted CAS (CAS3+, CAS4+), you can add new key with or without working keys available for all versions of CAS3+, CAS4 and CAS4+.


BDC/FEM Unlock

Autohex II with HW4 is the most safe tool that can unlock BMW BDC and FEM modules. No need to desolder and solder the BDC/FEM module when you are working with Autohex II, the job is done in one click.

-After you get BDC/FEM Secret Info File, you can:

-Make a new key even if all keys lost

-Change VIN, Ferquency

-Read DME ISN info from BDC/FEM

Microtronik AutoHex II Delete & Make New BMW FEM BDC Key:

Top 3: obdstar (X300 DP Plus, x300 pro4)


1). Obdstar X300 DP Plus – IMMO + ODO + Special functions

OBDSTAR X300 DP Plus is a new Android-based vehicle trouble diagnostic device developed for internet applications. It inherits from OBDSTAR advanced diagnosing technology and it is characterized by covering wide range of vehicles, featuring powerful function, and providing precise result. Through vehicle diagnostic OBD connector and variant mobile intelligent terminals, it achieves vehicle trouble diagnosis for full car model and full system vehicle.

Meanwhile, taking advantage of mobile internet, this device integrates more application and service, such as Maintenance Database, remote assistant, One Key Upgrade etc.

Hardware Advantages:

  1. Built-in VCI box
  2. 8-inch touchscreen
  3. Charge directly via OBD interface
  4. Practical and high-end gift box
  5. Industrial design with silicone case
  6. Back bracket design:prop on the steering wheel or stand on the table
  7. With Toyota simulate key 1
  8. P001 programmer: EEPROM adapter + RFID adapter + Key Renew adapter
  9. Add the clip of reading SOP 8PIN EEPROM
  10. C001/C002 circuit board to read and write chip data with welding
  11. IMMO induction coil to detect the key induction coil failure of the vehicle.
  12. Add wiring harness of ECU reading by OBD (for ECU cloning and switch activation)

Software Advantages:


  2. Renew Key
  3. Key programming
  4. Remote programming

Cluster Calibrate: wild vehicle coverage, pls check the carlist

Diagnosis: realize all vehicle systems diagnosis

Special Functions

TPS/ABS/EPB/DPF/TPMS/SRS Reset/Fuel Injector/Gear Learning/Battery Matching/ECU Programming/Throttle Matching/

Oil/service reset/Steering Angle Reset/Remote Manual Setting/Electronic Steering Reset/CVT Learning/value Reset

Obdstar x300dp plus IMMO car list

Obdstar x300dp plus ODO car list

ECU Clone

  1. ECU Clone, means ECU duplication.

The device copies all the data from the original vehicle ECU, and then writes all data copied into ECU with the same hardware to realize the same ECU function with the original vehicle.

  1. Clone directly when replacing a new or a used ECU!

Without online matching in 4S store or removal of ECU bonding wire for reading and writing! Directly write without dismantling OBD!

  1. Three features for ECU Clone:
  2. Free of 4S online:

break monopoly from 4S, benefiting automobile maintenance industry

  1. Simplified operation procedures: realize foolproof operation
  2. Non-dismantling with zero risks: read and write data without dismantling ECU

Switch Activation Function

(Today many instruments or audio of vehicles activate secondary power supply to go into power-on status by relevant module CAN communication on the vehicle, but sometimes an instrument or an audio is separated from vehicle CANBUS network, causing startup failure when it needs to be repaired by an auto technician. This function can simulate CAN communication to activate secondary power supply, so the instrument or the audio enters into power-on status. In this way, it not only can test and verify the instrument or the audio, but also save an enormous cost for an auto technician to purchase a large number of startup platforms of various vehicles and wiring harnesses!)

Add “Help” Functions

  1. including built-in testable vehicle models, upgrade announcement, features, help notes and wiring diagrams, etc.
  2. Carlist and upgrade announcement, all details are available on the device
  3. Customers can look up the features or uniquely support functions on the device
  4.  Help notes: built-in help notes for each model or function
  5. Wiring diagrams: built-in ECU wiring diagrams, more intuitionistic and convenient

OBDSTAR X300 DP Plus test vechile videos List:

2). Obdstar x300 pro4 – dedicated key programmer


Obdstar x300 pro4 is an all-purpose immobilizer programming device meticulously designed by OBDSTAR for locksmith. The device inherits the automobile immobilizer programming technology from OBDSTAR with a lot of advantages of early start, wide vehicle coverage, fast programming speed and special features. All-in-one machine structure, more convenient to use, full optimization hardware, running more stable, faster and smoother.

Obdstar x300 pro4 IMMO coverage

Obdstar x300 pro4 package:

Main Unit + Main Cable + Charger + Packing Box+KIA-20+OBD II-16

Connector+HONDA-3+HYUNDAI-10+P001 Programmer Unit+C001/C002 Circuit

Board+W001+Configuration List/Certificate/Quick Start Guide Fold

Top 4: Lonsdor K518S + LKE Smart Key Emulator


1). K518S main functions:

Odometer adjustment
Built-in Volkswagen 4th 5th adapter
Built-in Chip & remote detection module.
Free BMW FEM key programming

Car List for IMMO:

Europe: Audi, BMW,VW, Volvo, Citroen, Ferrari, Maserati, Fiat, Lamborghini, Jaguar, MG, Land Rover, Bentley, Lancia, Opel, Peugeot, Porsche, DS, Renault, Alfa Romeo, Smart, Borgward

America: Cadillac, Chevrolet, Dodge, GMC, Buick, Hummer, Ford, JEEP, Lincoln, Mercury

Asia: Honda, Hyundai, Isuzu, KIA, Lexus, Mazda, Mitsubishi, Nissan, Ssangyong, Subaru, Suzuki, Toyota, Shigaoka Queen

China: Iveco, Trumpchi, BYD, Geely, Chery, Great Wall, Young Lotus (Basically all Chinese car models are included)

Lonsdor K518S Key programmer Pros:

Volvo (S40/S60/S80/V40/V60/V70/C30/C70/XC60/XC70/XC90) full version (mechanical key, smart key, keyless-go) key programming

Toyota/Lexus smart key all lost offline via OBD with 5-in-1 LKE emulator (94/D4、98、39、88/A8、A9),

BMW CAS1/CAS2/CAS3/CAS3+/CAS3++/CAS4/CAS4+/FEM/BDC key programming

Mitsubishi all key lost via simulate chip with emulator

Mazda latest model of smart key programming w/o PIN code

Volkswagen/Audi/Skoda/Seat – MQB platform key programming & odometer adjustment

Porsche 911/997/Boxster/Cayman (2005-2010) key programming via LKE emulator w/o PIN code

Hyundai KIA –46 chip/ 46 smart key/ 47 smart key/ 8A smart key / read PIN code

Peugeot/Citroen/DS – read PIN code & add key or all key lost for most of models

Renault Latitude / Fluence key programming w/o 32-bit PIN code

Renualt Koleos (2010-2016) read PIN code to program via OBD

GM series 2010-2018 – support more than 80% models via read PIN code from BCM

Subaru all key lost via OBD reset PEPS

Land Rover and Jaguar key programming via OBD – support FK72/HPLA KVM version

Rolls-Royce Phantom key programming

Ferrari (458, F12, F149) – key programming via OBD

Jeep Grand Cherokee (2014-) – read PIN code to program

New Ssangyong series key programming w/o PIN code

Jeep Renegade (2017) key programming

Jeep Compass (2018) smart key programming

Mercedes-Benz (2014-FBS4) – support 166, 205, 213, 222 chassis w/o network or OEM tool

Maserati (2017) smart key programming—-support Levante, Ghibli, Quattroporte

MG6 – read PIN code to program via OBD

Smart 453 – read PIN code to program

Generate dedicated key chip – 4D, 46, 48, T5, 7936

Key chip identification & remote frequency detection

Lonsdor K518S Technical Parameter:

RFID: 125KHz ASK; 134.2KHz FSK

Battery capacity: 3800mAh

CPU: ARM Cortex-A7 Quad-core Processor Speed 1.34GHZ

Power supply: DC12V 1A

WIFI communication distance: 10m

Power port: 5.5×2.1mm

Display: 1024×600, 7 inch IPS capacitive screen

OBD port: OBD-II

Memory: eMMC 8G RAM 1G Comm port USB2.0-type B

OBDII protocols: ISO15765, ISO9141, ISO14230, SAEJ1850, KW1281, VW TP1.6 TP2.0 etc.

  1. Lonsdor LKE – Toyota/Lexus smart key programming via OBD for all key lost


1). Toyota/Lexus smart key programming via OBD for all key lost;

Support “94/4D, 98/39(128 bit), 88/A8, A9” smart key offline programming via OBD

2). Chip generation;

Generate emergency key to start the car when the dedicated chip is not available

3). Chip copy; Copy chip via collect and decode chip data (Cover wide

range of vehicle models, faster)

4). Chip simulation and conversion; Generate various kinds of chip in urgent situation

5). Chip decode; Support code calculation for most 46 smart key and blade key (include 4D)

6).Identify the working statue of the ignition coil and the type of key chip (Support all key lost)

7). Work with K518 to program Hyundai/Kia without PIN code

8). Work with K518 to program BYD without PIN code

9). Work with K518 to program Porsche Cayman, Boxster without PIN code

10). Work with K518 to program Mitsubishi (46/47) all key lost via OBD

Lonsdor K518S & LKE Smart Emulator Using Guide:

Watch youtube videos:

Top 5: Xhorse (VVDI2, VVDI MB, VVDI BMW, VVDI Key tool, Key tool Max)

1 – VVDI2



VVDI2 Pros:

1). VVDI2 All Authorization Kit Activated 13 Software List:
1. √  VV-01 VAG 4th immobilizer
2. √  VV-02 VAG 5th immobilizer
3. √  VV-03 VAG Copy 48 transponder by OBDII
4. √  VV-04 ID48 96Bit Copy
5. √  VV-05 VAG MQB Immobilizer
6. √  VB-01 BMW OBD
7. √  VB-02 BMW CAS4
8. √  VB-03 FEM/BDC Function
9. √  VP-01 Porsche immo data tool
10. √  VPSA-01 PSA
11. √  VK-01 Transponder Programmer
12. √  VJ-01 Passthru J2534
13. √  V7-01 Prepare Toyota H Chip

Read VVDI2 user manual

2). Update Online Free Lifetime

3). Open freely: OBD read MED17/EDC17 PIN / CS / MAC, calculate OBD data online, calculate EEPROM / FLASH for PIN/MAC/CS.

VVDI2 full using tips:

1). It connects to the server and synchronizes once every 31 days. This process is done automatically by itself for 1 day, internet connection is required for this process.

2) Toyota H Chip authorization,please get by yourself:Download Xhorse APP, register with your phone number,Select in xhorse update kit software bind,log in Customer Self Service,click Activate H. Then update your VVDI2 firmware.

Xhorse VVDI2 full – A good alternative of AVDI

A good alternative when you don’t want to pay for the AVDI modules.
It has VW (Audi, Seat, Skoda, Porsche, Bentley), Beemer and PSA support with key learning and so on. I don’t know how other peoples think, but AVDI is and was a good tool – but is damn expensive. The modules what this machine can do were cost more than 10.000.- euros. This alternative is good enough to do the allday work, and costs only $1600 from the official web page. From this year the ID48 cloning is free for all users, don’t imitate – innovate! There is only one thing with this toy what irritates me: you have a prompt in the program, that you have to update the software, but if you push on update button, nothing happens. To update the program you have to download & install the new sw as usual VVDI Prog, only the firmware update needs the official update manager.

Sometimes some functions aren’t activated, then you can ask for help.

2 –  VVDI BMW Tool


VVDI BMW Tool Functions:

1). Read EEPROM / Write EEPROM

u Read KM / Write KM

u Synchronize DME-CAS, CAS-ELV

2).Key Learn

u Get Key Info

u Write Key Info

u Load Key Info / Save Key Info

u Prepare dealer key with programmer

u Prepare dealer key with ignition switch

u Add key

u Program Key Info

u Repair Keyless Key

u Enable Key / Disable Key

u Clear DTC / Clear Shadow

3). File Make Key



4). Unlock Key

u Unlock with key info file

u Unlock with CAS1/CAS2/CAS3/CAS3+ EEPROM

5). File Change KM



u Cluster (E Series): M35080 EEPROM dump

u Cluster (F Series)

6). CAS Repair

Detail can be found in chapter 9 CAS Repair

CAS1(0K50E) OBDII Repair

ISTAP4* Version OBDII Repair


VVDI BMW Tool Pros:

1). Support E/F/G chassis Programming function
2). Support E/F/G chassis coding function
3). OBD key Key: Support CAS1/CAS2/CAS3/CAS3+/ISTAP/ etc.
4). File Generation Key: Supports CAS1/CAS2/CAS3/CAS3+/ISTAP/CAS4/CAs4+, etc.
5). Support FEM/BDC system to generate keys, replace FEM/BDC control unit, support reset mileage
6). Supports mileage correction CAS1/CAS2/CAS3/CAS3+/ISTAP/CAS4/CAs4+
7). Support for reading EEPROM and sync data for CAS1/CAS2/CAS3/CAS3 systems
8). Support simultaneous engine and CAS, synchronous ELV and CAS
9). Support reading ISN data from the engine
10). Support reset 8HP gearbox in F chassis.
11). Support exchange ECU and CAS.

12). Language: English, Italian, Spanish, German, Hungarian, Polish and Chinese


VVDI BMW is not only for locksmith, it has functions of coding and programming and much more.
Vvdi2 for bmw has possibility for manual coding and changing cars vo (vehicle order ) , emergency flash and retrofit options.

VVDI BMW Tool User Manual:


vvdi mb tool

Xhorse VVDI MB BGA TOOL Functions:

1).Read Write Key
Identification key, IR read write BE key, read v51, v67 version’s key password by NEC adapter, read activate blank BGA (OCF4)key, key current HASH(repair), renew, write into the used NEC key, write smart key etc.

2).Password Calculation
OBD read and calculate all(FBS3) can protocol EIS password, support BGA keys, NEC key, v51, v57 version password calculation, support all key lostW164,W216,W166,W209,W211,W212,W246,W212(old),W204, W207 etc, online calculation key password

3).ESL Tools
OBD(K line)read data, Renew ESL, replace ESL (no need to renew EIS), check ESL damage, repair W204 ESL

4).Read/ Write Gateway
Support OBD repair KM: W204, W207, W212, W251, W164,W211,W221,W216.W166.W172,W232,W205 etc
Support reading writing gateway EEPROM and FLASH:W211/W/164/W204/W207/W212/W221/W216 etc

5).EIS Tools
Read 8 write ES by OBD or ROBD auto detect, access to W164 W209 W211 without gateway. Read the old Motorola EIS(k-line)’s password.
Renew EIS, Replace EIS, Enable key, Disable key. Personalize W204 ESL
Test ESL Status/Working key etc

6).Prepare Key File
Online generate v11, v41, v51 version’s key file, support Motorola EIS
EPROM file, with high efficiency, 1009 successful generate

7).Program ECU/Gearbox/ISM

8). Workable models
Support renew ECU, gearbox and SM, write in VN, personalized etc

Model support IR/OBD:
W164, W164 2009+
A166, W197, W212, W218, A246
A169, W209, W211
W172, W204, A207
W204, W207, W212 only by dump
W209 only by dump
W215, W220

Keys version supported:
v03, v06, v08
v05, v07, v09
v59, v61


1).VVDI MB Tool Language: English,Polish,Spanish(Will add more in future)
2).Latest VVDI MB Tool Version: 5.0.3
3).Fastest Benz password calculation speed.
4).High quality, Professional Design.
5).Support all key lost:W210, W204, W207,W166, W230, W246, W212, W212(old),some W216, W164 2009- and some others. Future will add more.
6).Support FBS4 disable key function(Other function->FBS4 disable key)- Support W166/W205/W213/W218/W222/W246 type

Top 6. Autel MaxiIM IM608 / IM508

1). First Autel MaxiIM IM608


Autel MaxiIM IM608 is the most advanced and the unique all in one key programming and diagnostic tool that combines advanced key programming, all systems diagnostics, and advanced services in one Android based 10.1-inch touchscreen tablet. It is equipped with XP400 key programmer and MaxiFlash ECU programmer to provide complete coverage of IMMO and programming functions. Together with the ability to quickly diagnose all modules of the majority of the makes and models on the market, IM608 provides you with all special functions. It is the unprecedented key programming and diagnostic tool that you ever wanted

IM608 is a state of the art 10-inch Android-based touch screen tablet combining the most advanced key programming and immobilizer capabilities with OE-level diagnostics and service functions. Equipped with XP400 key programmer and MaxiFlash JVCI ECU programmer, IM608 is a comprehensive immobilizer and key programming tool and ideal for auto technicians and locksmiths. It combines the most advanced key programming and immobilizer experience with advanced automotive diagnostics and service functions, a 10-inch Android-based, touch-screen tablet with the latest in art. Autel MaxiIM IM608, a comprehensive, ideal immobilizer and key programming tool for automobile technicians and locksmiths.


Connect the IM608 tablet to the vehicle (via the Bluetooth VCI or Main Cable) and to the XP400 (via USB cable) to access IMMO related functions, including Key Learning, Remote Control Learning, Remote Control Add, etc. The software provides two methods to access IMMO functions
1. Smart Mode – for Guided and Automated Key Learning – step by step through a series of functions.
2. Expert Mode – for Advanced Key Learning – select a specific function.

1). PIN / CS Reading (Full Lost)
2). Key Generation
3). Key Programming
4). Command Introduction
5). Backup / Repair IMMO Data
6). IMMO ECU Brain Reset / Adaptation
7). IMMO ECU Brain Reset / Coding
8). BENZ 3rd Generation IMMO Key Splicing, Full Lost, Key Programming
9). BMW FEM / BDC Key Programming and ECU Adaptation
10). BMW CAS4 / 3/2 Key Programming
11). VW / AUDI MQB Key Programming, 48 Transponder (96-bit) Key Splicing, Full Lost, A6 Full Lost and More …

XP400 KEY & CHIP PROGRAMMER Function List:

Support PC
MCU / EEPROM Chips Read / Write
ECU Read / Write
MC9S12 Encryption Chip Read / Write
Key Read / Write
Mercedes Infrared Key Read / Write
Remote Frequency Detect
IC Card Read/Write

More details, read Autel MaxiIM IM608 user manual

2). Autel MaxiIM IM508 key programmer


Autel MaxiIM IM508 is a fast, easy-to-use, and ultraportable immobilizer and key programming device. IM508 is capable of providing extraordinary service functions for the immobilizer system. Together with the ability to quickly diagnose all modules of the majority of the makes and models on the market, IM508 provides you with superior special functions. IM508 is the perfect solution for shops and technicians who demand affordable and powerful IMMO and diagnostic services.

comprehensive immo & key chip programming:
IM508 Diagnostic Scan Tool can perform: Read PIN/CS(All Key Lost), key generation, key learning, remote learning on Benz FEM/BDC Key Learning/ECU Adaptation, BMW CAS3/2 Key Learning, VW/Audi/Skoda/Seat IMMO III/IV/V Add Key, All Key Lost, IMMO ECU reset/adaptation/refresh/coding, Transpronder read & write, EEPROM/MCU read & write. Being compatible with XP400 Key Programmer, you may choose to upgrade its programming capabilities further with XP400.

Professional Key Programmer
Autel IM508 is a professional car diagnostic scanner that provides extraordinary service functions for the immobilizer system, including: immobilizer system status,
key learning, key add, all keys lost, remote control learning, remote control add, chip read and write. It’s a professional solution for car keys and remote controls
and prevents your car from being stolen!

Autel MaxiIM IM508 vs. IM608 in IMMO & key programming function:


Top 7. Yanhua Mini ACDP key programmer (without dismantle the IMMO)


Full authorization including:

Support CAS1/CAS2/CAS3/CAS3+/CAS4/CAS4+/FEM/BDC Key Programming, newly Add CAS4/CAS4+ OBD Function

Read & Write BMW DME ISN Code by OBD

Read & Write BMW 35080, 35160DO WT

Read & Write Fujitsu CPU MB91F

MQB/MMC Instrument

Refresh BMW Keys

BMW FRM Programming

Land Rover Key Programming

Porsche BCM Key Programming Support Add Key & All Key Lost from 2010-2018

Clear EGS ISN on both 6HP & 8HP

Volvo Key Programming

Watch all Yanhua Mini ACDP operation guide on Youtube

Yanhua Mini ACDP Pros:

– Test car NO longer needs engines
– Programming no need soldering, no need to remove chip, no need to cut the line, no need to lift the pin.

– Compatible with IOS / Android/ PC

Top 8. Xtool X100 Pro2 or Xtool X100 Pad2

  1. XTOOL X100 Pro2 Auto Key Programmer

X100 Pro2 includes functions of key programming and dashboard recovery. This equipment is anti-seismic and durable, which can meet the actual needs of different users such as automobile repair factory and workshop.

Key Reading and Programming

Programming keys is easy with the XTOOL X100 Pro2, and you can do it on almost every North American and European vehicle. While the compatibility is limited on Asian models, this still makes it a versatile key programmer for both home users and professional locksmiths. Along with programming new keys, you can read keys from the IMMO memory. The XTOOL X100 Pro2 also supports remote programming.

Advanced Programming

Most key programmers at this price point can read and make keys, but the XTOOL X100 Pro2 takes this a step further. Included advanced features include programming VIN and IMMO data, as well as reading and adjusting the mileage.

XTOOL X100 Pro2 Pros:

IMMO and VIN programming included

Capable of reading keys from IMMO memory

Supports most vehicles from Europe, Asia, and North America

Anti-seismic and ruggedly built

Supports reading and reprogramming mileage

Excellent value for supported features

Free updates supported

XTOOL X100 Pro2 Cons:

May not work with vehicles pre-1996 or post-2011

Doesn’t support Japanese vehicles

  1. Xtool X100 Pad2 Pro key programmer


Xtool X100 PAD2 Pro is a wonderful tablet key programmer! It is not only provides customers with professional key programming, but also the most needed special functions for workshop. X-100 PAD2 is a tablet with the latest technologies to perform key programming, mileage adjustment, oil service light reset, timing belt service light reset, tire pressure warning light reset, EPB reset, throttle body reset, DPF reset, battery reset, steering angle calibration and OBD-II engine diagnosis, and is especially added with VW 4th & 5th IMMO.

Xtool X100 PAD2 Pros

Full IMMO and key programming capabilities

Interface is easy to navigate and use

Performs full OBDII diagnostics in addition to programming keys

4-system diagnosis with advanced reset functions

One-click automatic updates via Wi-Fi

Supports CAN BUS and UDS

Xtool X100 PAD2 Cons

Limited vehicle compatibility

Not all functions available for all supported vehicles

Top 9. SVCI V2020 & SVCI 2018

SVCI V2020 FVDI Full Version IMMO Diagnostic Programming Tool


SVCI V2020 Pros:

1). SVCI 2020 has fewer button batteries than SVCI 2018.
2) SVCI 2020 does not need to be activated, it will not lock the machine, and the serial number will not be lost.
3) SVCI 2020 has 19 more software than SVCI 2018:

ABRITES Commander for VAG V37.0/ BMW V10.5 / Mercedes V10.4 / Bikes V2.0/ Chrysler V3.4 / Daihatsu V1.4 / FIAT V7.6 / Ford V7.7 / Hyundai V4.4 / JLR V2.6 / Mitsubishi V3.7 / Nissan V5.7 / OPEL V7.5 / Porsche V7.1 / PSA V6.3 / Renault V7.4 / Suzuki V1.2 / Toyota V11.4 / Volvo V6.2

SVCI V2020 Cons:

FVDI SVCI V2020 & SVCI V2019 have no special functions.

But it has the new regular software and contains all the old software as well.

The hardware is compatible with the older software SVCI V2018 or the version of FVDI2, the older software have special function, then if SVCI V2020 & SVCI V2019 run the old software, it will have special functions.

Top 10. Autek IKey820 OBD key programmer


Autek IKey820 Pros:

1). Autek IKey820 OBD key programmer is 10 times better than Superobd SKP900.

2). Autek IKey820 can work with the car up to 2018 /2019 year and can update online continuously.

3). Superobd SKP900 can work with the car before 2015 / 2016 year and can’t update in the future.

4). Program key Via OBD

5). Has on-screen instruction instead of paper user manual

6). Best for: Ford, Lincoln, Mercury, Chrysler, Jeep, Dodge, GM, Buick, Cadillac, Chevrolet, Pontiac, Mitsubishi, Subaru

7). Good for: Citroen, DS, Ferrari, Fiat, GMC, Honda, Acura, Saab, Hyundai, Infiniti, Isuzu, Jaguar, Landrover, Kia, Lexus, Maserati, Mazda, MG, Nissan, Opel, Peugeot, Porsche, Renault, Scion, Smart, Suzuki, Toyota, VW, Audi, BMW, Mini, Benz etc.

8) Year: Up to 2018 / 2019 year.

Autek IKEY820 License for Ford 2018+ and Toyota G and H Chip All Key Lost Key Programming


Autek IKEY820 New License for GM, Grand Cheokee and Dodge Durango Key Programming


9). Free tokens: IKey 820 comes with 500 tokens. When you finish 500 tokens, you can reload another 200 tokens again and again.

Autek IKey820 Cons:

1). VAG 4th & 5th generation IMMO: not support, only support up to 3.5th generation IMMO.

2). Toyota G & H chip add key & all keys lost programming:

North American cars YES & no need simulator smart card.

The other regions add new key YES & all keys lost NO

Top 11. TMPro 2 Original Transponder Key Programmer


– TMPro2
Expensive alternative of Tango. The original hardware is cheap – and that’s the only thing what’s easy to get. The tool has lots of modules (208 at the moment) and the cheapest ones costs €100, but gives lots of modules over 1000 euro. It gives some modules that are able to use such binaries what no ther tool can, but they are insanely expensive. If money doesn’t matters, then this is the best choice what you can make; otherwise depends only on your customers what is what you have to build up: Tango or TMPro. The main software without modules and hardware is free to use, but is only able to tell about a binary file when that’s good or not. The main hardware is between 89-150 euro. I think I won’t pay for this nearly €30.000.- to have the full version. (Maybe cheaper if you buy the whole package together…)

What is TMPro2?

Transponder Maker Pro (also known as TMPro keymaker or TMPro2 keymaker) is a programmer and softwares for transponder key making, transponder key programming, transponder key copying and PIN code/ security code calculating. Programmer has to be connected to USB port of computer, it does not require external power supply. Main software user interface supports 14 languages – Bulgarian, English, French, Portuguese, Polish, Hungarian, Spanish, Serbian, Italian, Czech, Chinese, Greek, Turkish and Romanian. Programmer and all softwares are auto-updateable to latest version available on server.

TMPro are organized as modular softwares. At beginning you can purchase TMPro programmer without any additional softwares and use it only with main software. In the future when job comes to your workshop you can very fast and easy add new softwares by simple software purchasing system.

TMPro2 works with immobilizers eeprom dumps. You must have electronic knowledges and to know how to use soldering-desoldering tools and memory devices programmers. It is your choice what programmer you will use for reading memory devices – TMPro2 memory device programmer or other programmer. In order to program transponder you have to remove immobox/BSI/UCH unit from car, open it, desolder memory device or solder wires on testpoints, and read it. Depending of vehicle memory device can be serial eeprom, Motorola MCU, Microchip PIC MCU, ST10F269 MCU, Texas Instruments MCU etc… Next step is to program transponder. Last step is to solder back memory device, reassemble immobox/BSI/UCH and fit back to car.

That’s it for now, will be updated if I know anything important.


Related: 2020 Best Car Key Programmers Reviews


Hyundai IX35 Smart Key Programming by VVDI Key Tool Max & K518

In this instruction i will show you guide on how to use Lonsdor K518 and VVDI Key Tool Max to program smart key for Hyundai IX35.


What You Need?

VVDI Key Tool Max Programmer

Lonsdor K518 Key Programmer

Xhorse Universal Smart Proximity



Select “Vehicle Remote” and search “ix35”

Then select “Hyundai-[All remotes]”


Input Xhorse Universal Smart Proximity to coil hole and press “Generate remote”


Wait for proceeding complete

Hyundai-IX35-Smart-Key-Programming-by-VVDI-Key-Tool-Max-K518-3 Hyundai-IX35-Smart-Key-Programming-by-VVDI-Key-Tool-Max-K518-4





Then connect Lonsdor K518 to vehicle and enter menu

Select “Immobilization”–>”Hyundai”–>”Select from vehicle”–>”General area”


Select “ix35(EL)”–>”Smart Key”

Hyundai-IX35-Smart-Key-Programming-by-VVDI-Key-Tool-Max-K518-7 Hyundai-IX35-Smart-Key-Programming-by-VVDI-Key-Tool-Max-K518-8


Select “Program smart key”


Click your vehicle start button,then click OK to continue

Hyundai-IX35-Smart-Key-Programming-by-VVDI-Key-Tool-Max-K518-10 Hyundai-IX35-Smart-Key-Programming-by-VVDI-Key-Tool-Max-K518-11


Switch ignition off

Then it will ask you to input 6bit PIN code to continue programming,after then click continue


Click [OK],and then use the smart key to be programmed to vertically press the start button,or within 5 second to use the top of the smart key to press and hold the start button for 5 second,the security light will flash


Program successful,do you want to program next one?


Click [OK] to do second key,just repeat procedures

Finally,test your new keys.
